- Startmotor
-
HC-Cargo Startmotor
- Startmotor
-
HC-Cargo Startmotor
Artikelnr: F032114264
HC-Cargo Startmotor
Voltage: 12, kW: 4.2, No./teeth: 11, Rotation: CW
Beskrivning
Voltage: 12
kW: 4.2
Mount. flange: 89.00
Drive dist.: 21.00
Mount. hole 3 mm: 11.00
Mount. hole 2 mm: 11.00
Mount. hole 1 mm: 11.00
Dist./back: 247.00
Dist./front: 69.50
No./teeth: 11
B+: M10
Thread length mm: 19.00
Position/50: 40
Terminal 50: M4-6.30
Gear type: GR
Dist. 2: 87.50
Dist. 3: 127.00
Dist. mm: 89.50
Rotation: CW
Position/b-: 30
B-: M8
Total length mm: 349.50
No./mount. holes: 3 (0)
kW: 4.2
Mount. flange: 89.00
Drive dist.: 21.00
Mount. hole 3 mm: 11.00
Mount. hole 2 mm: 11.00
Mount. hole 1 mm: 11.00
Dist./back: 247.00
Dist./front: 69.50
No./teeth: 11
B+: M10
Thread length mm: 19.00
Position/50: 40
Terminal 50: M4-6.30
Gear type: GR
Dist. 2: 87.50
Dist. 3: 127.00
Dist. mm: 89.50
Rotation: CW
Position/b-: 30
B-: M8
Total length mm: 349.50
No./mount. holes: 3 (0)
Filer
Specifikation
| B+ | M10 |
|---|---|
| B- | M8 |
| No./teeth | 11 |
| Mount. flange | 89.00 |
| No./mount. holes | 3 (0) |
| Position/50 | 40 |
| Position/b- | 30 |
| Dist. 2 | 87.50 |
| Dist. 3 | 127.00 |
| Rotation | CW |
| Dist./back | 247.00 |
| Dist./front | 69.50 |
| Drive dist. | 21.00 |
| Gear type | GR |
| kW | 4.2 |
| Terminal 50 | M4-6.30 |
| Voltage | 12 |
| Total length | 349.50 mm |
| Dist. | 89.50 mm |
| Thread length | 19.00 mm |
| Mount. hole 3 | 11.00 mm |
| Mount. hole 2 | 11.00 mm |
| Mount. hole 1 | 11.00 mm |
-
OEM
AZF4181, AZF4186, AZF4224, AZF4576, F032114264, 11.131.292, 11.131.697, 11.131.711, 11.131.848, 320-09022, 320-09026, 320-09032, 320-09035, 320-09144, 320-09346, 320-09409, 320-09452, 320-09454 -
Konkurrentreferens
CST21133, DRS0117, IS1105, MS84, S5009L, S9173, S9173(LETRIKA), 25-4161, 600.237.112, 8441, 30230N, 254560 -
Normaliserat artikelnummer
azf4181, azf4186, azf4224, azf4576, cst21133, drs0117, f032114264, is1105, ms84, s5009l, s9173, s9173letrika, 8441, 30230n, 254161, 254560, 11131292, 11131697, 11131711, 11131848, 32009022, 32009026, 32009032, 32009035, 32009144, 32009346, 32009409, 32009452, 32009454, 600237112 -
Passar modeller
Case Model: L10.5 Model series: L10.5 Model type: Wheel Loaders and Dozers Brand of engine: 1104C-44 Approved: Yes Caterpillar Model: M92 Model series: M92 Model type: Engine Brand of engine: 1104C-44 Approved: Yes Caterpillar Model: M92B Model series: M92B Model type: Engine Brand of engine: 1104C-44 Approved: Yes Daedong Model: DK753 Model series: DK753 Model type: Ag Tractors Brand of engine: 1104C-44 Body: Tractor Approved: Yes Daedong Model: FX651 Model series: FX651 Model type: Ag Tractors Brand of engine: 1104C-44 Body: Tractor Approved: Yes Daedong Model: LX500L Model series: LX500L Model type: Ag Tractors Brand of engine: 1104C-44 Body: Tractor Approved: Yes Gehl Model: 7610 Model series: 7610 Model type: Skid Steer Loaders Brand of engine: 1104C-44 Approved: Yes Hyster Model: H.500XM Model series: H.500XM Model type: Forklifts Brand of engine: 1104C-44 Approved: Yes Hyster Model: H3.50XM Model series: H3.50XM Model type: Forklifts Brand of engine: 1104C-44 Approved: Yes Hyster Model: H4.00XM-5 Model series: H4.00XM-5 Model type: Forklifts Brand of engine: 1104C-44 Approved: Yes Hyster Model: H4.00XM-6 Model series: H4.00XM-6 Model type: Forklifts Brand of engine: 1104C-44 Approved: Yes Hyster Model: H4.00XMS-6 Model series: H4.00XMS-6 Model type: Forklifts Brand of engine: 1104C-44 Approved: Yes Hyster Model: H4.50XM Model series: H4.50XM Model type: Forklifts Brand of engine: 1104C-44 Approved: Yes Hyster Model: H5.50XM Model series: H5.50XM Model type: Forklifts Brand of engine: 1104C-44 Approved: Yes Hyundai Model: HR70C-9 Model series: HR70C-9 Model type: Rollers Brand of engine: 1104C-44 Approved: Yes JCB Model: 1110 Model series: 1110 Model type: Skid Steer Loaders Brand of engine: JCB444TA (Tier 3) Approved: Yes JCB Model: 190 Model series: 190 Model type: Skid Steer Loaders Brand of engine: JCB444TA (Tier 3) Approved: Yes JCB Model: 212S Model series: 212S Model type: Tractor/Loader/Backhoes Brand of engine: 1104C-44 Approved: Yes JCB Model: 2CX Model series: 2CX Model type: Tractor/Loader/Backhoes Brand of engine: 1104C-44 Approved: Yes JCB Model: 2CXL Model series: 2CXL Model type: Wheel Loaders and Dozers Brand of engine: 1104C-44 Approved: Yes JCB Model: 3C 14 & 3C LL Model series: 3C 14 & 3C LL Model type: Tractor/Loader/Backhoes Brand of engine: JCB444T (Tier 3) Approved: Yes JCB Model: 3C LL Model series: 3C LL Model type: Tractor/Loader/Backhoes Brand of engine: JCB444T (Tier 2) Approved: Yes JCB Model: 3C-14 FT Model series: 3C-14 FT Model type: Tractor/Loader/Backhoes Brand of engine: JCB444T (Tier 2) Approved: Yes JCB Model: 3C-14, 3C-15 & 3C LL Model series: 3C-14, 3C-15 & 3C LL Model type: Tractor/Loader/Backhoes Brand of engine: JCB444T (Tier 3) Approved: Yes JCB Model: 3C-15 FT Model series: 3C-15 FT Model type: Tractor/Loader/Backhoes Brand of engine: JCB444T (Tier 2) Approved: Yes JCB Model: 3CX CONTRACTOR Model series: 3CX CONTRACTOR Model type: Tractor/Loader/Backhoes Brand of engine: JCB444T (Tier 2) Approved: Yes JCB Model: 3CX CONTRACTOR Model series: 3CX CONTRACTOR Model type: Tractor/Loader/Backhoes Brand of engine: JCB444TA (Tier 3) Approved: Yes JCB Model: 3CX ECO SERIES (OPT) Model series: 3CX ECO SERIES (OPT) Model type: Tractor/Loader/Backhoes Brand of engine: JCB444T (Tier 3) Approved: Yes JCB Model: 3CX ECO SERIES Model series: 3CX ECO SERIES Model type: Tractor/Loader/Backhoes Brand of engine: JCB444T (Tier 2) Approved: Yes JCB Model: 3CX ECO SERIES Model series: 3CX ECO SERIES Model type: Tractor/Loader/Backhoes Brand of engine: JCB444T (Tier 3) Approved: Yes JCB Model: 3CX Model series: 3CX Model type: Tractor/Loader/Backhoes Brand of engine: 1104C-44 Approved: Yes JCB Model: 3CX Model series: 3CX Model type: Tractor/Loader/Backhoes Brand of engine: JCB444T (Tier 2) Approved: Yes JCB Model: 3CX Pothole Master Model series: 3CX Pothole Master Model type: Tractor/Loader/Backhoes Brand of engine: JCB444 Ecomax-109 Approved: Yes JCB Model: 3CX SERIES Model series: 3CX SERIES Model type: Tractor/Loader/Backhoes Brand of engine: JCB444T (Tier 2) Approved: Yes JCB Model: 3CX SERIES Model series: 3CX SERIES Model type: Tractor/Loader/Backhoes Brand of engine: JCB444TA (Tier 3) Approved: Yes JCB Model: 3CX-14 FT Model series: 3CX-14 FT Model type: Tractor/Loader/Backhoes Brand of engine: JCB444T (Tier 2) Approved: Yes JCB Model: 3CX-14, 3CX-15 & 3CX-17 Model series: 3CX-14, 3CX-15 & 3CX-17 Model type: Tractor/Loader/Backhoes Brand of engine: JCB444T (Tier 3) Approved: Yes JCB Model: 3CX-15 FT Model series: 3CX-15 FT Model type: Tractor/Loader/Backhoes Brand of engine: JCB444T (Tier 2) Approved: Yes JCB Model: 3CX-17 FT Model series: 3CX-17 FT Model type: Tractor/Loader/Backhoes Brand of engine: JCB444T (Tier 2) Approved: Yes JCB Model: 3DX Premium Model series: 3DX Premium Model type: Tractor/Loader/Backhoes Brand of engine: JCB448 Ecomax-145 Approved: Yes JCB Model: 3DXL Model series: 3DXL Model type: Wheel Loaders and Dozers Brand of engine: JCB448 Ecomax-145 Approved: Yes JCB Model: 407 Model series: 407 Model type: Wheel Loaders and Dozers Brand of engine: 1104C-44 Approved: Yes JCB Model: 407 ZX Model series: 407 ZX Model type: Wheel Loaders and Dozers Brand of engine: 1104C-44 Approved: Yes JCB Model: 408 Model series: 408 Model type: Wheel Loaders and Dozers Brand of engine: 1104C-44 Approved: Yes JCB Model: 408 ZX Model series: 408 ZX Model type: Wheel Loaders and Dozers Brand of engine: 1104C-44 Approved: Yes JCB Model: 409 Model series: 409 Model type: Wheel Loaders and Dozers Brand of engine: 1104C-44 Approved: Yes JCB Model: 409 ZX Model series: 409 ZX Model type: Wheel Loaders and Dozers Brand of engine: 1104C-44 Approved: Yes JCB Model: 410 ZX Model series: 410 ZX Model type: Wheel Loaders and Dozers Brand of engine: 1104C-44 Approved: Yes JCB Model: 411 AGRI Model series: 411 AGRI Model type: Wheel Loaders and Dozers Brand of engine: JCB444TA (Tier 3) Approved: Yes JCB Model: 411 HT Model series: 411 HT Model type: Wheel Loaders and Dozers Brand of engine: JCB444TA (Tier 3) Approved: Yes JCB Model: 411 Model series: 411 Model type: Wheel Loaders and Dozers Brand of engine: JCB444TA (Tier 3) Approved: Yes JCB Model: 412S AGRI Model series: 412S AGRI Model type: Wheel Loaders and Dozers Brand of engine: JCB444TA (Tier 3) Approved: Yes JCB Model: 416 HT Model series: 416 HT Model type: Wheel Loaders and Dozers Brand of engine: JCB444TA (Tier 3) Approved: Yes JCB Model: 416 Model series: 416 Model type: Wheel Loaders and Dozers Brand of engine: JCB444TA (Tier 3) Approved: Yes JCB Model: 422ZX Model series: 422ZX Model type: Wheel Loaders and Dozers Brand of engine: JCB444TA (Tier 3) Approved: Yes JCB Model: 426ZX Model series: 426ZX Model type: Wheel Loaders and Dozers Brand of engine: JCB444TA (Tier 3) Approved: Yes JCB Model: 430ZX Model series: 430ZX Model type: Wheel Loaders and Dozers Brand of engine: JCB444 Ecomax-125 Approved: Yes JCB Model: 4CX ECO Model series: 4CX ECO Model type: Tractor/Loader/Backhoes Brand of engine: JCB444 Ecomax-109 Approved: Yes JCB Model: 4CX Model series: 4CX Model type: Tractor/Loader/Backhoes Brand of engine: JCB444T (Tier 2) Approved: Yes JCB Model: 4CX SERIES Model series: 4CX SERIES Model type: Tractor/Loader/Backhoes Brand of engine: JCB444T (Tier 2) Approved: Yes JCB Model: 4CX SERIES Model series: 4CX SERIES Model type: Tractor/Loader/Backhoes Brand of engine: JCB444TA (Tier 3) Approved: Yes JCB Model: 4CX-14 FT Model series: 4CX-14 FT Model type: Tractor/Loader/Backhoes Brand of engine: JCB444T (Tier 2) Approved: Yes JCB Model: 4CX-14, 4CX-15 & 4CX-17 Model series: 4CX-14, 4CX-15 & 4CX-17 Model type: Tractor/Loader/Backhoes Brand of engine: JCB444T (Tier 3) Approved: Yes JCB Model: 4CX-15 FT Model series: 4CX-15 FT Model type: Tractor/Loader/Backhoes Brand of engine: JCB444T (Tier 2) Approved: Yes JCB Model: 4CX-17 FT Model series: 4CX-17 FT Model type: Tractor/Loader/Backhoes Brand of engine: JCB444T (Tier 2) Approved: Yes JCB Model: 4DX Model series: 4DX Model type: Tractor/Loader/Backhoes Brand of engine: JCB444 Ecomax-109 Approved: Yes JCB Model: 506-36 LOADALL (NA MKT) Model series: 506-36 LOADALL (NA MKT) Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 3) Approved: Yes JCB Model: 506C HL LOADALL Model series: 506C HL LOADALL Model type: Rough Terrain Forklifts Brand of engine: 1104C-44 Approved: Yes JCB Model: 506C HL LOADALL Model series: 506C HL LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 2) Approved: Yes JCB Model: 506C LOADALL Model series: 506C LOADALL Model type: Rough Terrain Forklifts Brand of engine: 1104C-44 Approved: Yes JCB Model: 506C LOADALL Model series: 506C LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 2) Approved: Yes JCB Model: 507-42 LOADALL (NA MKT) Model series: 507-42 LOADALL (NA MKT) Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 3) Approved: Yes JCB Model: 508C LOADALL Model series: 508C LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 2) Approved: Yes JCB Model: 509-42 LOADALL (NA MKT) Model series: 509-42 LOADALL (NA MKT) Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 3) Approved: Yes JCB Model: 510-56 LOADALL (NA MKT) Model series: 510-56 LOADALL (NA MKT) Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 3) Approved: Yes JCB Model: 512-56 LOADALL (NA MKT) Model series: 512-56 LOADALL (NA MKT) Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 3) Approved: Yes JCB Model: 520 LOADALL Model series: 520 LOADALL Model type: Rough Terrain Forklifts Brand of engine: 1104C-44 Approved: Yes JCB Model: 520-50 LOADALL Model series: 520-50 LOADALL Model type: Rough Terrain Forklifts Brand of engine: 1104C-44 Approved: Yes JCB Model: 524-50 LOADALL Model series: 524-50 LOADALL Model type: Rough Terrain Forklifts Brand of engine: 1104C-44 Approved: Yes JCB Model: 524-50 LOADALL Model series: 524-50 LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 3) Approved: Yes JCB Model: 525-50 LOADALL Model series: 525-50 LOADALL Model type: Rough Terrain Forklifts Brand of engine: 1104C-44 Approved: Yes JCB Model: 526-55 &526S LOADALL Model series: 526-55 &526S LOADALL Model type: Rough Terrain Forklifts Brand of engine: 1104C-44 Approved: Yes JCB Model: 527-55 LOADALL Model series: 527-55 LOADALL Model type: Rough Terrain Forklifts Brand of engine: 1104C-44 Approved: Yes JCB Model: 527-55 LOADALL Model series: 527-55 LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 3) Approved: Yes JCB Model: 527-58 LOADALL WASTEMASTER Model series: 527-58 LOADALL WASTEMASTER Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 3) Approved: Yes JCB Model: 528-70 & 528S LOADALL Model series: 528-70 & 528S LOADALL Model type: Rough Terrain Forklifts Brand of engine: 1104C-44 Approved: Yes JCB Model: 530-70 LOADALL Model series: 530-70 LOADALL Model type: Rough Terrain Forklifts Brand of engine: 1104C-44 Approved: Yes JCB Model: 531-70 LOADALL Model series: 531-70 LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444 Ecomax-109 Approved: Yes JCB Model: 531-70 LOADALL Model series: 531-70 LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 3) Approved: Yes JCB Model: 531-70T LOADALL Model series: 531-70T LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 2) Approved: Yes JCB Model: 531-70T LOADALL Model series: 531-70T LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 3) Approved: Yes JCB Model: 533-105 LOADALL Model series: 533-105 LOADALL Model type: Rough Terrain Forklifts Brand of engine: 1104C-44 Approved: Yes JCB Model: 533-105 LOADALL Model series: 533-105 LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 3) Approved: Yes JCB Model: 533-105T LOADALL Model series: 533-105T LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 2) Approved: Yes JCB Model: 533-105T LOADALL Model series: 533-105T LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 3) Approved: Yes JCB Model: 535-125 & 535-140 LOADALL Model series: 535-125 & 535-140 LOADALL Model type: Rough Terrain Forklifts Brand of engine: 1104C-44 Approved: Yes JCB Model: 535-125 HI VIZ LOADALL Model series: 535-125 HI VIZ LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 3) Approved: Yes JCB Model: 535-125T HI VIZ LOADALL Model series: 535-125T HI VIZ LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 2) Approved: Yes JCB Model: 535-125T HI VIZ LOADALL Model series: 535-125T HI VIZ LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 3) Approved: Yes JCB Model: 535-140 HI VIZ LOADALL Model series: 535-140 HI VIZ LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 3) Approved: Yes JCB Model: 535-140 LOADALL Model series: 535-140 LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 2) Approved: Yes JCB Model: 535-140T HI VIZ LOADALL Model series: 535-140T HI VIZ LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 2) Approved: Yes JCB Model: 535-140T HI VIZ LOADALL Model series: 535-140T HI VIZ LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 3) Approved: Yes JCB Model: 535-95 LOADALL Model series: 535-95 LOADALL Model type: Rough Terrain Forklifts Brand of engine: 1104C-44 Approved: Yes JCB Model: 535-95 LOADALL Model series: 535-95 LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444 Ecomax-109 Approved: Yes JCB Model: 535-95 LOADALL Model series: 535-95 LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 3) Approved: Yes JCB Model: 535-95T LOADALL Model series: 535-95T LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 2) Approved: Yes JCB Model: 535-95T LOADALL Model series: 535-95T LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 3) Approved: Yes JCB Model: 536-60 LOADALL Model series: 536-60 LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 3) Approved: Yes JCB Model: 536-60T LOADALL Model series: 536-60T LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 2) Approved: Yes JCB Model: 536-60T LOADALL Model series: 536-60T LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 3) Approved: Yes JCB Model: 540 LOADALL Model series: 540 LOADALL Model type: Rough Terrain Forklifts Brand of engine: 1104C-44 Approved: Yes JCB Model: 540-140 & 540-170 LOADALL Model series: 540-140 & 540-170 LOADALL Model type: Rough Terrain Forklifts Brand of engine: 1104C-44 Approved: Yes JCB Model: 540-140 LOADALL Model series: 540-140 LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 3) Approved: Yes JCB Model: 540-140T LOADALL Model series: 540-140T LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 2) Approved: Yes JCB Model: 540-140T LOADALL Model series: 540-140T LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 3) Approved: Yes JCB Model: 540-170 LOADALL Model series: 540-170 LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444 Ecomax-109 Approved: Yes JCB Model: 540-170T LOADALL (OPT 1). Model series: 540-170T LOADALL (OPT 1). Model type: Rough Terrain Forklifts Brand of engine: JCB444TA (Tier 3) Approved: Yes JCB Model: 540-170T LOADALL (OPT). Model series: 540-170T LOADALL (OPT). Model type: Rough Terrain Forklifts Brand of engine: JCB444TA (Tier 3) Approved: Yes JCB Model: 540-170T LOADALL Model series: 540-170T LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 2) Approved: Yes JCB Model: 540-170T LOADALL Model series: 540-170T LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 3) Approved: Yes JCB Model: 540-200 LOADALL Model series: 540-200 LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 2) Approved: Yes JCB Model: 540-200 LOADALL Model series: 540-200 LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 3) Approved: Yes JCB Model: 540-70 LOADALL Model series: 540-70 LOADALL Model type: Rough Terrain Forklifts Brand of engine: 1104C-44 Approved: Yes JCB Model: 541-70 LOADALL Model series: 541-70 LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444 Ecomax-109 Approved: Yes JCB Model: 541-70T LOADALL Model series: 541-70T LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 2) Approved: Yes JCB Model: 541-70T LOADALL Model series: 541-70T LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 3) Approved: Yes JCB Model: 550-140 LOADALL Model series: 550-140 LOADALL Model type: Rough Terrain Forklifts Brand of engine: 1104C-44 Approved: Yes JCB Model: 550-140 LOADALL Model series: 550-140 LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 2) Approved: Yes JCB Model: 550-140 LOADALL Model series: 550-140 LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 3) Approved: Yes JCB Model: 550-170 LOADALL Model series: 550-170 LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 2) Approved: Yes JCB Model: 550-170 LOADALL Model series: 550-170 LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 3) Approved: Yes JCB Model: 550-80 LOADALL Model series: 550-80 LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444 Ecomax-125 Approved: Yes JCB Model: 5CX Wastemaster Model series: 5CX Wastemaster Model type: Tractor/Loader/Backhoes Brand of engine: JCB444 Ecomax-109 Approved: Yes JCB Model: 926 Model series: 926 Model type: Rough Terrain Forklifts Brand of engine: 1104C-44 Approved: Yes JCB Model: 926 Model series: 926 Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 3) Approved: Yes JCB Model: 930 Model series: 930 Model type: Rough Terrain Forklifts Brand of engine: 1104C-44 Approved: Yes JCB Model: 930 Model series: 930 Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 3) Approved: Yes JCB Model: 940 Model series: 940 Model type: Rough Terrain Forklifts Brand of engine: 1104C-44 Approved: Yes JCB Model: 940 Model series: 940 Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 3) Approved: Yes JCB Model: G90X Model series: G90X Model type: Generator Sets Brand of engine: JCB444 Ecomax-125 Approved: Yes JCB Model: JS 130 Model series: JS 130 Model type: Excavators Brand of engine: JCB444 Ecomax-109 Approved: Yes JCB Model: JS 145 Model series: JS 145 Model type: Excavators Brand of engine: JCB444 Ecomax-109 Approved: Yes JCB Model: JS 160 Model series: JS 160 Model type: Excavators Brand of engine: JCB444 Ecomax-109 Approved: Yes JCB Model: JS 180 Model series: JS 180 Model type: Excavators Brand of engine: JCB444 Ecomax-109 Approved: Yes JCB Model: JS 190 Model series: JS 190 Model type: Excavators Brand of engine: JCB444 Ecomax-109 Approved: Yes JCB Model: JS145W Model series: JS145W Model type: Excavators Brand of engine: JCB448 Ecomax-145 Approved: Yes JCB Model: JS160LC Model series: JS160LC Model type: Excavators Brand of engine: JCB444 Ecomax-109 Approved: Yes JCB Model: JS160W Model series: JS160W Model type: Excavators Brand of engine: JCB448 Ecomax-145 Approved: Yes JCB Model: JS200LC Model series: JS200LC Model type: Excavators Brand of engine: JCB444 Ecomax-109 Approved: Yes JCB Model: JS20MH Model series: JS20MH Model type: Excavators Brand of engine: JCB448 Ecomax-145 Approved: Yes JCB Model: JS210 Model series: JS210 Model type: Excavators Brand of engine: JCB444 Ecomax-109 Approved: Yes JCB Model: JS220LC Model series: JS220LC Model type: Excavators Brand of engine: JCB444 Ecomax-109 Approved: Yes JCB Model: JS235LC Model series: JS235LC Model type: Excavators Brand of engine: JCB444 Ecomax-109 Approved: Yes JCB Model: Loadall 540-170 Model series: Loadall 540-170 Model type: Rough Terrain Forklifts Brand of engine: JCB444 Ecomax-109 Approved: Yes JCB Model: ROBOT 1110 Model series: ROBOT 1110 Model type: Skid Steer Loaders Brand of engine: 1104C-44 Approved: Yes JCB Model: ROBOT 1110 TRACKED Model series: ROBOT 1110 TRACKED Model type: Skid Steer Loaders Brand of engine: 1104C-44 Approved: Yes JCB Model: ROBOT 190 Model series: ROBOT 190 Model type: Skid Steer Loaders Brand of engine: 1104C-44 Approved: Yes JCB Model: ROBOT 190 TRACKED Model series: ROBOT 190 TRACKED Model type: Skid Steer Loaders Brand of engine: 1104C-44 Approved: Yes JCB Model: TM320 Model series: TM320 Model type: Rough Terrain Forklifts Brand of engine: JCB444 Ecomax-125 Approved: Yes JCB Model: TM320S Model series: TM320S Model type: Rough Terrain Forklifts Brand of engine: JCB448 Ecomax-145 Approved: Yes JCB Model: Various Models Model series: Various Models Approved: Yes JCB Model: Various Models Model series: Various Models From date: 01-01-1985 Approved: Yes JCB Model: VMT 860 Model series: VMT 860 Model type: Rollers Brand of engine: JCB444 Ecomax-125 Approved: Yes JCB Model: VTM860 Model series: VTM860 Model type: Rollers Brand of engine: JCB444TA (Tier 3) Approved: Yes John Deere Model: 1500 Model series: 1500 Model type: Sprayers Brand of engine: 1104C-44 Approved: Yes Landini Model: 7865 Model series: 7865 Model type: Ag Tractors Brand of engine: 1104C-44 Body: Tractor Approved: Yes Landini Model: 8865 Model series: 8865 Model type: Ag Tractors Brand of engine: 1104C-44 Body: Tractor Approved: Yes Landini Model: REX 80 Model series: REX 80 Model type: Ag Tractors Brand of engine: 1104C-44 Body: Tractor Approved: Yes Landini Model: TECHNOFARM 75 Model series: TECHNOFARM 75 Model type: Ag Tractors Brand of engine: 1104C-44 Body: Tractor Approved: Yes Landini Model: TECHNOFARM 85 Model series: TECHNOFARM 85 Model type: Ag Tractors Brand of engine: 1104C-44 Body: Tractor Approved: Yes Manitou Model: 2099 Model series: 2099 Model type: Skid Steer Loaders Brand of engine: 1104C-44 Approved: Yes Manitou Model: K-D HAWK SERIES Model series: K-D HAWK SERIES Model type: Rough Terrain Forklifts Brand of engine: 1104C-44 Approved: Yes Manitou Model: M 26.2-50.4 SRS Model series: M 26.2-50.4 SRS Model type: Rough Terrain Forklifts Brand of engine: 1104C-44 Approved: Yes Manitou Model: M SERIES Model series: M SERIES Model type: Rough Terrain Forklifts Brand of engine: 1104C-44 Approved: Yes Manitou Model: MC 30 Model series: MC 30 Model type: Rough Terrain Forklifts Brand of engine: 1104C-44 Approved: Yes Manitou Model: MC 30/40/50 Model series: MC 30/40/50 Model type: Rough Terrain Forklifts Brand of engine: 1104C-44 Approved: Yes Manitou Model: MC 40 / MC 50 Model series: MC 40 / MC 50 Model type: Rough Terrain Forklifts Brand of engine: 1104C-44 Approved: Yes Manitou Model: MLT 526 Model series: MLT 526 Model type: Rough Terrain Forklifts Brand of engine: 1104C-44 Approved: Yes Manitou Model: MLT 629 Model series: MLT 629 Model type: Rough Terrain Forklifts Brand of engine: 1104C-44 Approved: Yes Manitou Model: MSI 40 H / 50 H Model series: MSI 40 H / 50 H Model type: Rough Terrain Forklifts Brand of engine: 1104C-44 Approved: Yes Manitou Model: MSI 40/50 Model series: MSI 40/50 Model type: Forklifts Brand of engine: 1104C-44 Approved: Yes Manitou Model: MT 728 Model series: MT 728 Model type: Rough Terrain Forklifts Brand of engine: 1104C-44 Approved: Yes Manitou Model: MT 732/ MT 932 / MT 928 Model series: MT 732/ MT 932 / MT 928 Model type: Rough Terrain Forklifts Brand of engine: 1104C-44 Approved: Yes Manitou Model: MT 732/ MT 932 Model series: MT 732/ MT 932 Model type: Rough Terrain Forklifts Brand of engine: 1104C-44 Approved: Yes Manitou Model: MT 940 L Model series: MT 940 L Model type: Rough Terrain Forklifts Brand of engine: 1104C-44 Approved: Yes Manitou Model: MT1436 Model series: MT1436 Model type: Rough Terrain Forklifts Brand of engine: 1104C-44 Approved: Yes McCormick Model: C 70 2WD Model series: C 70 2WD Model type: Ag Tractors Brand of engine: 1104C-44 Body: Tractor Approved: Yes McCormick Model: C 70 4WD Model series: C 70 4WD Model type: Ag Tractors Brand of engine: 1104C-44 Body: Tractor Approved: Yes McCormick Model: C75 MAX & C85 MAX 2WD Model series: C75 MAX & C85 MAX 2WD Model type: Ag Tractors Brand of engine: 1104C-44 Body: Tractor Approved: Yes McCormick Model: C75 MAX & C85 MAX 4WD Model series: C75 MAX & C85 MAX 4WD Model type: Ag Tractors Brand of engine: 1104C-44 Body: Tractor Approved: Yes McCormick Model: C75L MONDIAL Model series: C75L MONDIAL Model type: Ag Tractors Brand of engine: 1104C-44 Body: Tractor Approved: Yes McCormick Model: C85L MONDIAL Model series: C85L MONDIAL Model type: Ag Tractors Brand of engine: 1104C-44 Body: Tractor Approved: Yes McCormick Model: F75 Model series: F75 Model type: Ag Tractors Brand of engine: 1104C-44 Body: Tractor Approved: Yes McCormick Model: F85 Model series: F85 Model type: Ag Tractors Brand of engine: 1104C-44 Body: Tractor Approved: Yes McCormick Model: MB65 Model series: MB65 Model type: Ag Tractors Brand of engine: 1104C-44 Body: Tractor Approved: Yes McCormick Model: MB75 Model series: MB75 Model type: Ag Tractors Brand of engine: 1104C-44 Body: Tractor Approved: Yes McCormick Model: MB85 Model series: MB85 Model type: Ag Tractors Brand of engine: 1104C-44 Body: Tractor Approved: Yes Still Model: 5-6T Model series: 5-6T Model type: Forklifts Brand of engine: 1104C-44 Approved: Yes Terex Model: 3000 SRS TX66 Model series: 3000 SRS TX66 Model type: Rough Terrain Forklifts Brand of engine: 1104C-44 Approved: Yes Terex Model: PT 7000 Model series: PT 7000 Model type: Dumpers/Tenders Brand of engine: 1104C-44 Approved: Yes Terex Model: PT/PS 5000 Model series: PT/PS 5000 Model type: Dumpers/Tenders Brand of engine: 1104C-44 Approved: Yes Terex Model: PT/PS 6000 Model series: PT/PS 6000 Model type: Dumpers/Tenders Brand of engine: 1104C-44 Approved: Yes Terex Model: S100/S105 Model series: S100/S105 Model type: Aerial Lifts Brand of engine: 1104C-44 Approved: Yes Terex Model: S120/125 Model series: S120/125 Model type: Aerial Lifts Brand of engine: 1104C-44 Approved: Yes Terex Model: TL120 Model series: TL120 Model type: Wheel Loaders and Dozers Brand of engine: 1104C-44 Approved: Yes Terex Model: Z-135/70 Model series: Z-135/70 Model type: Aerial Lifts Brand of engine: 1104C-44 Approved: Yes Ursus Model: 5024 Model series: 5024 Model type: Ag Tractors Brand of engine: 1104C-44 Body: Tractor Approved: Yes Yale Model: GDP35LG Model series: GDP35LG Model type: Forklifts Brand of engine: 1104C-44 Approved: Yes Yale Model: GDP40LG Model series: GDP40LG Model type: Forklifts Brand of engine: 1104C-44 Approved: Yes Yale Model: GDP45MG Model series: GDP45MG Model type: Forklifts Brand of engine: 1104C-44 Approved: Yes Yale Model: GDP50MG Model series: GDP50MG Model type: Forklifts Brand of engine: 1104C-44 Approved: Yes Yale Model: GDP55MG Model series: GDP55MG Model type: Forklifts Brand of engine: 1104C-44 Approved: Yes 1 / 43
-
Beskrivning
Voltage: 12
kW: 4.2
Mount. flange: 89.00
Drive dist.: 21.00
Mount. hole 3 mm: 11.00
Mount. hole 2 mm: 11.00
Mount. hole 1 mm: 11.00
Dist./back: 247.00
Dist./front: 69.50
No./teeth: 11
B+: M10
Thread length mm: 19.00
Position/50: 40
Terminal 50: M4-6.30
Gear type: GR
Dist. 2: 87.50
Dist. 3: 127.00
Dist. mm: 89.50
Rotation: CW
Position/b-: 30
B-: M8
Total length mm: 349.50
No./mount. holes: 3 (0)Filer
-
Specifikation
B+ M10 B- M8 No./teeth 11 Mount. flange 89.00 No./mount. holes 3 (0) Position/50 40 Position/b- 30 Dist. 2 87.50 Dist. 3 127.00 Rotation CW Dist./back 247.00 Dist./front 69.50 Drive dist. 21.00 Gear type GR kW 4.2 Terminal 50 M4-6.30 Voltage 12 Total length 349.50 mm Dist. 89.50 mm Thread length 19.00 mm Mount. hole 3 11.00 mm Mount. hole 2 11.00 mm Mount. hole 1 11.00 mm -
Fordonsmatchning
-
OEM
AZF4181, AZF4186, AZF4224, AZF4576, F032114264, 11.131.292, 11.131.697, 11.131.711, 11.131.848, 320-09022, 320-09026, 320-09032, 320-09035, 320-09144, 320-09346, 320-09409, 320-09452, 320-09454 -
Konkurrentreferens
CST21133, DRS0117, IS1105, MS84, S5009L, S9173, S9173(LETRIKA), 25-4161, 600.237.112, 8441, 30230N, 254560 -
Normaliserat artikelnummer
azf4181, azf4186, azf4224, azf4576, cst21133, drs0117, f032114264, is1105, ms84, s5009l, s9173, s9173letrika, 8441, 30230n, 254161, 254560, 11131292, 11131697, 11131711, 11131848, 32009022, 32009026, 32009032, 32009035, 32009144, 32009346, 32009409, 32009452, 32009454, 600237112 -
Passar modeller
Case Model: L10.5 Model series: L10.5 Model type: Wheel Loaders and Dozers Brand of engine: 1104C-44 Approved: Yes Caterpillar Model: M92 Model series: M92 Model type: Engine Brand of engine: 1104C-44 Approved: Yes Caterpillar Model: M92B Model series: M92B Model type: Engine Brand of engine: 1104C-44 Approved: Yes Daedong Model: DK753 Model series: DK753 Model type: Ag Tractors Brand of engine: 1104C-44 Body: Tractor Approved: Yes Daedong Model: FX651 Model series: FX651 Model type: Ag Tractors Brand of engine: 1104C-44 Body: Tractor Approved: Yes Daedong Model: LX500L Model series: LX500L Model type: Ag Tractors Brand of engine: 1104C-44 Body: Tractor Approved: Yes Gehl Model: 7610 Model series: 7610 Model type: Skid Steer Loaders Brand of engine: 1104C-44 Approved: Yes Hyster Model: H.500XM Model series: H.500XM Model type: Forklifts Brand of engine: 1104C-44 Approved: Yes Hyster Model: H3.50XM Model series: H3.50XM Model type: Forklifts Brand of engine: 1104C-44 Approved: Yes Hyster Model: H4.00XM-5 Model series: H4.00XM-5 Model type: Forklifts Brand of engine: 1104C-44 Approved: Yes Hyster Model: H4.00XM-6 Model series: H4.00XM-6 Model type: Forklifts Brand of engine: 1104C-44 Approved: Yes Hyster Model: H4.00XMS-6 Model series: H4.00XMS-6 Model type: Forklifts Brand of engine: 1104C-44 Approved: Yes Hyster Model: H4.50XM Model series: H4.50XM Model type: Forklifts Brand of engine: 1104C-44 Approved: Yes Hyster Model: H5.50XM Model series: H5.50XM Model type: Forklifts Brand of engine: 1104C-44 Approved: Yes Hyundai Model: HR70C-9 Model series: HR70C-9 Model type: Rollers Brand of engine: 1104C-44 Approved: Yes JCB Model: 1110 Model series: 1110 Model type: Skid Steer Loaders Brand of engine: JCB444TA (Tier 3) Approved: Yes JCB Model: 190 Model series: 190 Model type: Skid Steer Loaders Brand of engine: JCB444TA (Tier 3) Approved: Yes JCB Model: 212S Model series: 212S Model type: Tractor/Loader/Backhoes Brand of engine: 1104C-44 Approved: Yes JCB Model: 2CX Model series: 2CX Model type: Tractor/Loader/Backhoes Brand of engine: 1104C-44 Approved: Yes JCB Model: 2CXL Model series: 2CXL Model type: Wheel Loaders and Dozers Brand of engine: 1104C-44 Approved: Yes JCB Model: 3C 14 & 3C LL Model series: 3C 14 & 3C LL Model type: Tractor/Loader/Backhoes Brand of engine: JCB444T (Tier 3) Approved: Yes JCB Model: 3C LL Model series: 3C LL Model type: Tractor/Loader/Backhoes Brand of engine: JCB444T (Tier 2) Approved: Yes JCB Model: 3C-14 FT Model series: 3C-14 FT Model type: Tractor/Loader/Backhoes Brand of engine: JCB444T (Tier 2) Approved: Yes JCB Model: 3C-14, 3C-15 & 3C LL Model series: 3C-14, 3C-15 & 3C LL Model type: Tractor/Loader/Backhoes Brand of engine: JCB444T (Tier 3) Approved: Yes JCB Model: 3C-15 FT Model series: 3C-15 FT Model type: Tractor/Loader/Backhoes Brand of engine: JCB444T (Tier 2) Approved: Yes JCB Model: 3CX CONTRACTOR Model series: 3CX CONTRACTOR Model type: Tractor/Loader/Backhoes Brand of engine: JCB444T (Tier 2) Approved: Yes JCB Model: 3CX CONTRACTOR Model series: 3CX CONTRACTOR Model type: Tractor/Loader/Backhoes Brand of engine: JCB444TA (Tier 3) Approved: Yes JCB Model: 3CX ECO SERIES (OPT) Model series: 3CX ECO SERIES (OPT) Model type: Tractor/Loader/Backhoes Brand of engine: JCB444T (Tier 3) Approved: Yes JCB Model: 3CX ECO SERIES Model series: 3CX ECO SERIES Model type: Tractor/Loader/Backhoes Brand of engine: JCB444T (Tier 2) Approved: Yes JCB Model: 3CX ECO SERIES Model series: 3CX ECO SERIES Model type: Tractor/Loader/Backhoes Brand of engine: JCB444T (Tier 3) Approved: Yes JCB Model: 3CX Model series: 3CX Model type: Tractor/Loader/Backhoes Brand of engine: 1104C-44 Approved: Yes JCB Model: 3CX Model series: 3CX Model type: Tractor/Loader/Backhoes Brand of engine: JCB444T (Tier 2) Approved: Yes JCB Model: 3CX Pothole Master Model series: 3CX Pothole Master Model type: Tractor/Loader/Backhoes Brand of engine: JCB444 Ecomax-109 Approved: Yes JCB Model: 3CX SERIES Model series: 3CX SERIES Model type: Tractor/Loader/Backhoes Brand of engine: JCB444T (Tier 2) Approved: Yes JCB Model: 3CX SERIES Model series: 3CX SERIES Model type: Tractor/Loader/Backhoes Brand of engine: JCB444TA (Tier 3) Approved: Yes JCB Model: 3CX-14 FT Model series: 3CX-14 FT Model type: Tractor/Loader/Backhoes Brand of engine: JCB444T (Tier 2) Approved: Yes JCB Model: 3CX-14, 3CX-15 & 3CX-17 Model series: 3CX-14, 3CX-15 & 3CX-17 Model type: Tractor/Loader/Backhoes Brand of engine: JCB444T (Tier 3) Approved: Yes JCB Model: 3CX-15 FT Model series: 3CX-15 FT Model type: Tractor/Loader/Backhoes Brand of engine: JCB444T (Tier 2) Approved: Yes JCB Model: 3CX-17 FT Model series: 3CX-17 FT Model type: Tractor/Loader/Backhoes Brand of engine: JCB444T (Tier 2) Approved: Yes JCB Model: 3DX Premium Model series: 3DX Premium Model type: Tractor/Loader/Backhoes Brand of engine: JCB448 Ecomax-145 Approved: Yes JCB Model: 3DXL Model series: 3DXL Model type: Wheel Loaders and Dozers Brand of engine: JCB448 Ecomax-145 Approved: Yes JCB Model: 407 Model series: 407 Model type: Wheel Loaders and Dozers Brand of engine: 1104C-44 Approved: Yes JCB Model: 407 ZX Model series: 407 ZX Model type: Wheel Loaders and Dozers Brand of engine: 1104C-44 Approved: Yes JCB Model: 408 Model series: 408 Model type: Wheel Loaders and Dozers Brand of engine: 1104C-44 Approved: Yes JCB Model: 408 ZX Model series: 408 ZX Model type: Wheel Loaders and Dozers Brand of engine: 1104C-44 Approved: Yes JCB Model: 409 Model series: 409 Model type: Wheel Loaders and Dozers Brand of engine: 1104C-44 Approved: Yes JCB Model: 409 ZX Model series: 409 ZX Model type: Wheel Loaders and Dozers Brand of engine: 1104C-44 Approved: Yes JCB Model: 410 ZX Model series: 410 ZX Model type: Wheel Loaders and Dozers Brand of engine: 1104C-44 Approved: Yes JCB Model: 411 AGRI Model series: 411 AGRI Model type: Wheel Loaders and Dozers Brand of engine: JCB444TA (Tier 3) Approved: Yes JCB Model: 411 HT Model series: 411 HT Model type: Wheel Loaders and Dozers Brand of engine: JCB444TA (Tier 3) Approved: Yes JCB Model: 411 Model series: 411 Model type: Wheel Loaders and Dozers Brand of engine: JCB444TA (Tier 3) Approved: Yes JCB Model: 412S AGRI Model series: 412S AGRI Model type: Wheel Loaders and Dozers Brand of engine: JCB444TA (Tier 3) Approved: Yes JCB Model: 416 HT Model series: 416 HT Model type: Wheel Loaders and Dozers Brand of engine: JCB444TA (Tier 3) Approved: Yes JCB Model: 416 Model series: 416 Model type: Wheel Loaders and Dozers Brand of engine: JCB444TA (Tier 3) Approved: Yes JCB Model: 422ZX Model series: 422ZX Model type: Wheel Loaders and Dozers Brand of engine: JCB444TA (Tier 3) Approved: Yes JCB Model: 426ZX Model series: 426ZX Model type: Wheel Loaders and Dozers Brand of engine: JCB444TA (Tier 3) Approved: Yes JCB Model: 430ZX Model series: 430ZX Model type: Wheel Loaders and Dozers Brand of engine: JCB444 Ecomax-125 Approved: Yes JCB Model: 4CX ECO Model series: 4CX ECO Model type: Tractor/Loader/Backhoes Brand of engine: JCB444 Ecomax-109 Approved: Yes JCB Model: 4CX Model series: 4CX Model type: Tractor/Loader/Backhoes Brand of engine: JCB444T (Tier 2) Approved: Yes JCB Model: 4CX SERIES Model series: 4CX SERIES Model type: Tractor/Loader/Backhoes Brand of engine: JCB444T (Tier 2) Approved: Yes JCB Model: 4CX SERIES Model series: 4CX SERIES Model type: Tractor/Loader/Backhoes Brand of engine: JCB444TA (Tier 3) Approved: Yes JCB Model: 4CX-14 FT Model series: 4CX-14 FT Model type: Tractor/Loader/Backhoes Brand of engine: JCB444T (Tier 2) Approved: Yes JCB Model: 4CX-14, 4CX-15 & 4CX-17 Model series: 4CX-14, 4CX-15 & 4CX-17 Model type: Tractor/Loader/Backhoes Brand of engine: JCB444T (Tier 3) Approved: Yes JCB Model: 4CX-15 FT Model series: 4CX-15 FT Model type: Tractor/Loader/Backhoes Brand of engine: JCB444T (Tier 2) Approved: Yes JCB Model: 4CX-17 FT Model series: 4CX-17 FT Model type: Tractor/Loader/Backhoes Brand of engine: JCB444T (Tier 2) Approved: Yes JCB Model: 4DX Model series: 4DX Model type: Tractor/Loader/Backhoes Brand of engine: JCB444 Ecomax-109 Approved: Yes JCB Model: 506-36 LOADALL (NA MKT) Model series: 506-36 LOADALL (NA MKT) Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 3) Approved: Yes JCB Model: 506C HL LOADALL Model series: 506C HL LOADALL Model type: Rough Terrain Forklifts Brand of engine: 1104C-44 Approved: Yes JCB Model: 506C HL LOADALL Model series: 506C HL LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 2) Approved: Yes JCB Model: 506C LOADALL Model series: 506C LOADALL Model type: Rough Terrain Forklifts Brand of engine: 1104C-44 Approved: Yes JCB Model: 506C LOADALL Model series: 506C LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 2) Approved: Yes JCB Model: 507-42 LOADALL (NA MKT) Model series: 507-42 LOADALL (NA MKT) Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 3) Approved: Yes JCB Model: 508C LOADALL Model series: 508C LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 2) Approved: Yes JCB Model: 509-42 LOADALL (NA MKT) Model series: 509-42 LOADALL (NA MKT) Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 3) Approved: Yes JCB Model: 510-56 LOADALL (NA MKT) Model series: 510-56 LOADALL (NA MKT) Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 3) Approved: Yes JCB Model: 512-56 LOADALL (NA MKT) Model series: 512-56 LOADALL (NA MKT) Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 3) Approved: Yes JCB Model: 520 LOADALL Model series: 520 LOADALL Model type: Rough Terrain Forklifts Brand of engine: 1104C-44 Approved: Yes JCB Model: 520-50 LOADALL Model series: 520-50 LOADALL Model type: Rough Terrain Forklifts Brand of engine: 1104C-44 Approved: Yes JCB Model: 524-50 LOADALL Model series: 524-50 LOADALL Model type: Rough Terrain Forklifts Brand of engine: 1104C-44 Approved: Yes JCB Model: 524-50 LOADALL Model series: 524-50 LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 3) Approved: Yes JCB Model: 525-50 LOADALL Model series: 525-50 LOADALL Model type: Rough Terrain Forklifts Brand of engine: 1104C-44 Approved: Yes JCB Model: 526-55 &526S LOADALL Model series: 526-55 &526S LOADALL Model type: Rough Terrain Forklifts Brand of engine: 1104C-44 Approved: Yes JCB Model: 527-55 LOADALL Model series: 527-55 LOADALL Model type: Rough Terrain Forklifts Brand of engine: 1104C-44 Approved: Yes JCB Model: 527-55 LOADALL Model series: 527-55 LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 3) Approved: Yes JCB Model: 527-58 LOADALL WASTEMASTER Model series: 527-58 LOADALL WASTEMASTER Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 3) Approved: Yes JCB Model: 528-70 & 528S LOADALL Model series: 528-70 & 528S LOADALL Model type: Rough Terrain Forklifts Brand of engine: 1104C-44 Approved: Yes JCB Model: 530-70 LOADALL Model series: 530-70 LOADALL Model type: Rough Terrain Forklifts Brand of engine: 1104C-44 Approved: Yes JCB Model: 531-70 LOADALL Model series: 531-70 LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444 Ecomax-109 Approved: Yes JCB Model: 531-70 LOADALL Model series: 531-70 LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 3) Approved: Yes JCB Model: 531-70T LOADALL Model series: 531-70T LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 2) Approved: Yes JCB Model: 531-70T LOADALL Model series: 531-70T LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 3) Approved: Yes JCB Model: 533-105 LOADALL Model series: 533-105 LOADALL Model type: Rough Terrain Forklifts Brand of engine: 1104C-44 Approved: Yes JCB Model: 533-105 LOADALL Model series: 533-105 LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 3) Approved: Yes JCB Model: 533-105T LOADALL Model series: 533-105T LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 2) Approved: Yes JCB Model: 533-105T LOADALL Model series: 533-105T LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 3) Approved: Yes JCB Model: 535-125 & 535-140 LOADALL Model series: 535-125 & 535-140 LOADALL Model type: Rough Terrain Forklifts Brand of engine: 1104C-44 Approved: Yes JCB Model: 535-125 HI VIZ LOADALL Model series: 535-125 HI VIZ LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 3) Approved: Yes JCB Model: 535-125T HI VIZ LOADALL Model series: 535-125T HI VIZ LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 2) Approved: Yes JCB Model: 535-125T HI VIZ LOADALL Model series: 535-125T HI VIZ LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 3) Approved: Yes JCB Model: 535-140 HI VIZ LOADALL Model series: 535-140 HI VIZ LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 3) Approved: Yes JCB Model: 535-140 LOADALL Model series: 535-140 LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 2) Approved: Yes JCB Model: 535-140T HI VIZ LOADALL Model series: 535-140T HI VIZ LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 2) Approved: Yes JCB Model: 535-140T HI VIZ LOADALL Model series: 535-140T HI VIZ LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 3) Approved: Yes JCB Model: 535-95 LOADALL Model series: 535-95 LOADALL Model type: Rough Terrain Forklifts Brand of engine: 1104C-44 Approved: Yes JCB Model: 535-95 LOADALL Model series: 535-95 LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444 Ecomax-109 Approved: Yes JCB Model: 535-95 LOADALL Model series: 535-95 LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 3) Approved: Yes JCB Model: 535-95T LOADALL Model series: 535-95T LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 2) Approved: Yes JCB Model: 535-95T LOADALL Model series: 535-95T LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 3) Approved: Yes JCB Model: 536-60 LOADALL Model series: 536-60 LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 3) Approved: Yes JCB Model: 536-60T LOADALL Model series: 536-60T LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 2) Approved: Yes JCB Model: 536-60T LOADALL Model series: 536-60T LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 3) Approved: Yes JCB Model: 540 LOADALL Model series: 540 LOADALL Model type: Rough Terrain Forklifts Brand of engine: 1104C-44 Approved: Yes JCB Model: 540-140 & 540-170 LOADALL Model series: 540-140 & 540-170 LOADALL Model type: Rough Terrain Forklifts Brand of engine: 1104C-44 Approved: Yes JCB Model: 540-140 LOADALL Model series: 540-140 LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 3) Approved: Yes JCB Model: 540-140T LOADALL Model series: 540-140T LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 2) Approved: Yes JCB Model: 540-140T LOADALL Model series: 540-140T LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 3) Approved: Yes JCB Model: 540-170 LOADALL Model series: 540-170 LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444 Ecomax-109 Approved: Yes JCB Model: 540-170T LOADALL (OPT 1). Model series: 540-170T LOADALL (OPT 1). Model type: Rough Terrain Forklifts Brand of engine: JCB444TA (Tier 3) Approved: Yes JCB Model: 540-170T LOADALL (OPT). Model series: 540-170T LOADALL (OPT). Model type: Rough Terrain Forklifts Brand of engine: JCB444TA (Tier 3) Approved: Yes JCB Model: 540-170T LOADALL Model series: 540-170T LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 2) Approved: Yes JCB Model: 540-170T LOADALL Model series: 540-170T LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 3) Approved: Yes JCB Model: 540-200 LOADALL Model series: 540-200 LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 2) Approved: Yes JCB Model: 540-200 LOADALL Model series: 540-200 LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 3) Approved: Yes JCB Model: 540-70 LOADALL Model series: 540-70 LOADALL Model type: Rough Terrain Forklifts Brand of engine: 1104C-44 Approved: Yes JCB Model: 541-70 LOADALL Model series: 541-70 LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444 Ecomax-109 Approved: Yes JCB Model: 541-70T LOADALL Model series: 541-70T LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 2) Approved: Yes JCB Model: 541-70T LOADALL Model series: 541-70T LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 3) Approved: Yes JCB Model: 550-140 LOADALL Model series: 550-140 LOADALL Model type: Rough Terrain Forklifts Brand of engine: 1104C-44 Approved: Yes JCB Model: 550-140 LOADALL Model series: 550-140 LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 2) Approved: Yes JCB Model: 550-140 LOADALL Model series: 550-140 LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 3) Approved: Yes JCB Model: 550-170 LOADALL Model series: 550-170 LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 2) Approved: Yes JCB Model: 550-170 LOADALL Model series: 550-170 LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 3) Approved: Yes JCB Model: 550-80 LOADALL Model series: 550-80 LOADALL Model type: Rough Terrain Forklifts Brand of engine: JCB444 Ecomax-125 Approved: Yes JCB Model: 5CX Wastemaster Model series: 5CX Wastemaster Model type: Tractor/Loader/Backhoes Brand of engine: JCB444 Ecomax-109 Approved: Yes JCB Model: 926 Model series: 926 Model type: Rough Terrain Forklifts Brand of engine: 1104C-44 Approved: Yes JCB Model: 926 Model series: 926 Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 3) Approved: Yes JCB Model: 930 Model series: 930 Model type: Rough Terrain Forklifts Brand of engine: 1104C-44 Approved: Yes JCB Model: 930 Model series: 930 Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 3) Approved: Yes JCB Model: 940 Model series: 940 Model type: Rough Terrain Forklifts Brand of engine: 1104C-44 Approved: Yes JCB Model: 940 Model series: 940 Model type: Rough Terrain Forklifts Brand of engine: JCB444T (Tier 3) Approved: Yes JCB Model: G90X Model series: G90X Model type: Generator Sets Brand of engine: JCB444 Ecomax-125 Approved: Yes JCB Model: JS 130 Model series: JS 130 Model type: Excavators Brand of engine: JCB444 Ecomax-109 Approved: Yes JCB Model: JS 145 Model series: JS 145 Model type: Excavators Brand of engine: JCB444 Ecomax-109 Approved: Yes JCB Model: JS 160 Model series: JS 160 Model type: Excavators Brand of engine: JCB444 Ecomax-109 Approved: Yes JCB Model: JS 180 Model series: JS 180 Model type: Excavators Brand of engine: JCB444 Ecomax-109 Approved: Yes JCB Model: JS 190 Model series: JS 190 Model type: Excavators Brand of engine: JCB444 Ecomax-109 Approved: Yes JCB Model: JS145W Model series: JS145W Model type: Excavators Brand of engine: JCB448 Ecomax-145 Approved: Yes JCB Model: JS160LC Model series: JS160LC Model type: Excavators Brand of engine: JCB444 Ecomax-109 Approved: Yes JCB Model: JS160W Model series: JS160W Model type: Excavators Brand of engine: JCB448 Ecomax-145 Approved: Yes JCB Model: JS200LC Model series: JS200LC Model type: Excavators Brand of engine: JCB444 Ecomax-109 Approved: Yes JCB Model: JS20MH Model series: JS20MH Model type: Excavators Brand of engine: JCB448 Ecomax-145 Approved: Yes JCB Model: JS210 Model series: JS210 Model type: Excavators Brand of engine: JCB444 Ecomax-109 Approved: Yes JCB Model: JS220LC Model series: JS220LC Model type: Excavators Brand of engine: JCB444 Ecomax-109 Approved: Yes JCB Model: JS235LC Model series: JS235LC Model type: Excavators Brand of engine: JCB444 Ecomax-109 Approved: Yes JCB Model: Loadall 540-170 Model series: Loadall 540-170 Model type: Rough Terrain Forklifts Brand of engine: JCB444 Ecomax-109 Approved: Yes JCB Model: ROBOT 1110 Model series: ROBOT 1110 Model type: Skid Steer Loaders Brand of engine: 1104C-44 Approved: Yes JCB Model: ROBOT 1110 TRACKED Model series: ROBOT 1110 TRACKED Model type: Skid Steer Loaders Brand of engine: 1104C-44 Approved: Yes JCB Model: ROBOT 190 Model series: ROBOT 190 Model type: Skid Steer Loaders Brand of engine: 1104C-44 Approved: Yes JCB Model: ROBOT 190 TRACKED Model series: ROBOT 190 TRACKED Model type: Skid Steer Loaders Brand of engine: 1104C-44 Approved: Yes JCB Model: TM320 Model series: TM320 Model type: Rough Terrain Forklifts Brand of engine: JCB444 Ecomax-125 Approved: Yes JCB Model: TM320S Model series: TM320S Model type: Rough Terrain Forklifts Brand of engine: JCB448 Ecomax-145 Approved: Yes JCB Model: Various Models Model series: Various Models Approved: Yes JCB Model: Various Models Model series: Various Models From date: 01-01-1985 Approved: Yes JCB Model: VMT 860 Model series: VMT 860 Model type: Rollers Brand of engine: JCB444 Ecomax-125 Approved: Yes JCB Model: VTM860 Model series: VTM860 Model type: Rollers Brand of engine: JCB444TA (Tier 3) Approved: Yes John Deere Model: 1500 Model series: 1500 Model type: Sprayers Brand of engine: 1104C-44 Approved: Yes Landini Model: 7865 Model series: 7865 Model type: Ag Tractors Brand of engine: 1104C-44 Body: Tractor Approved: Yes Landini Model: 8865 Model series: 8865 Model type: Ag Tractors Brand of engine: 1104C-44 Body: Tractor Approved: Yes Landini Model: REX 80 Model series: REX 80 Model type: Ag Tractors Brand of engine: 1104C-44 Body: Tractor Approved: Yes Landini Model: TECHNOFARM 75 Model series: TECHNOFARM 75 Model type: Ag Tractors Brand of engine: 1104C-44 Body: Tractor Approved: Yes Landini Model: TECHNOFARM 85 Model series: TECHNOFARM 85 Model type: Ag Tractors Brand of engine: 1104C-44 Body: Tractor Approved: Yes Manitou Model: 2099 Model series: 2099 Model type: Skid Steer Loaders Brand of engine: 1104C-44 Approved: Yes Manitou Model: K-D HAWK SERIES Model series: K-D HAWK SERIES Model type: Rough Terrain Forklifts Brand of engine: 1104C-44 Approved: Yes Manitou Model: M 26.2-50.4 SRS Model series: M 26.2-50.4 SRS Model type: Rough Terrain Forklifts Brand of engine: 1104C-44 Approved: Yes Manitou Model: M SERIES Model series: M SERIES Model type: Rough Terrain Forklifts Brand of engine: 1104C-44 Approved: Yes Manitou Model: MC 30 Model series: MC 30 Model type: Rough Terrain Forklifts Brand of engine: 1104C-44 Approved: Yes Manitou Model: MC 30/40/50 Model series: MC 30/40/50 Model type: Rough Terrain Forklifts Brand of engine: 1104C-44 Approved: Yes Manitou Model: MC 40 / MC 50 Model series: MC 40 / MC 50 Model type: Rough Terrain Forklifts Brand of engine: 1104C-44 Approved: Yes Manitou Model: MLT 526 Model series: MLT 526 Model type: Rough Terrain Forklifts Brand of engine: 1104C-44 Approved: Yes Manitou Model: MLT 629 Model series: MLT 629 Model type: Rough Terrain Forklifts Brand of engine: 1104C-44 Approved: Yes Manitou Model: MSI 40 H / 50 H Model series: MSI 40 H / 50 H Model type: Rough Terrain Forklifts Brand of engine: 1104C-44 Approved: Yes Manitou Model: MSI 40/50 Model series: MSI 40/50 Model type: Forklifts Brand of engine: 1104C-44 Approved: Yes Manitou Model: MT 728 Model series: MT 728 Model type: Rough Terrain Forklifts Brand of engine: 1104C-44 Approved: Yes Manitou Model: MT 732/ MT 932 / MT 928 Model series: MT 732/ MT 932 / MT 928 Model type: Rough Terrain Forklifts Brand of engine: 1104C-44 Approved: Yes Manitou Model: MT 732/ MT 932 Model series: MT 732/ MT 932 Model type: Rough Terrain Forklifts Brand of engine: 1104C-44 Approved: Yes Manitou Model: MT 940 L Model series: MT 940 L Model type: Rough Terrain Forklifts Brand of engine: 1104C-44 Approved: Yes Manitou Model: MT1436 Model series: MT1436 Model type: Rough Terrain Forklifts Brand of engine: 1104C-44 Approved: Yes McCormick Model: C 70 2WD Model series: C 70 2WD Model type: Ag Tractors Brand of engine: 1104C-44 Body: Tractor Approved: Yes McCormick Model: C 70 4WD Model series: C 70 4WD Model type: Ag Tractors Brand of engine: 1104C-44 Body: Tractor Approved: Yes McCormick Model: C75 MAX & C85 MAX 2WD Model series: C75 MAX & C85 MAX 2WD Model type: Ag Tractors Brand of engine: 1104C-44 Body: Tractor Approved: Yes McCormick Model: C75 MAX & C85 MAX 4WD Model series: C75 MAX & C85 MAX 4WD Model type: Ag Tractors Brand of engine: 1104C-44 Body: Tractor Approved: Yes McCormick Model: C75L MONDIAL Model series: C75L MONDIAL Model type: Ag Tractors Brand of engine: 1104C-44 Body: Tractor Approved: Yes McCormick Model: C85L MONDIAL Model series: C85L MONDIAL Model type: Ag Tractors Brand of engine: 1104C-44 Body: Tractor Approved: Yes McCormick Model: F75 Model series: F75 Model type: Ag Tractors Brand of engine: 1104C-44 Body: Tractor Approved: Yes McCormick Model: F85 Model series: F85 Model type: Ag Tractors Brand of engine: 1104C-44 Body: Tractor Approved: Yes McCormick Model: MB65 Model series: MB65 Model type: Ag Tractors Brand of engine: 1104C-44 Body: Tractor Approved: Yes McCormick Model: MB75 Model series: MB75 Model type: Ag Tractors Brand of engine: 1104C-44 Body: Tractor Approved: Yes McCormick Model: MB85 Model series: MB85 Model type: Ag Tractors Brand of engine: 1104C-44 Body: Tractor Approved: Yes Still Model: 5-6T Model series: 5-6T Model type: Forklifts Brand of engine: 1104C-44 Approved: Yes Terex Model: 3000 SRS TX66 Model series: 3000 SRS TX66 Model type: Rough Terrain Forklifts Brand of engine: 1104C-44 Approved: Yes Terex Model: PT 7000 Model series: PT 7000 Model type: Dumpers/Tenders Brand of engine: 1104C-44 Approved: Yes Terex Model: PT/PS 5000 Model series: PT/PS 5000 Model type: Dumpers/Tenders Brand of engine: 1104C-44 Approved: Yes Terex Model: PT/PS 6000 Model series: PT/PS 6000 Model type: Dumpers/Tenders Brand of engine: 1104C-44 Approved: Yes Terex Model: S100/S105 Model series: S100/S105 Model type: Aerial Lifts Brand of engine: 1104C-44 Approved: Yes Terex Model: S120/125 Model series: S120/125 Model type: Aerial Lifts Brand of engine: 1104C-44 Approved: Yes Terex Model: TL120 Model series: TL120 Model type: Wheel Loaders and Dozers Brand of engine: 1104C-44 Approved: Yes Terex Model: Z-135/70 Model series: Z-135/70 Model type: Aerial Lifts Brand of engine: 1104C-44 Approved: Yes Ursus Model: 5024 Model series: 5024 Model type: Ag Tractors Brand of engine: 1104C-44 Body: Tractor Approved: Yes Yale Model: GDP35LG Model series: GDP35LG Model type: Forklifts Brand of engine: 1104C-44 Approved: Yes Yale Model: GDP40LG Model series: GDP40LG Model type: Forklifts Brand of engine: 1104C-44 Approved: Yes Yale Model: GDP45MG Model series: GDP45MG Model type: Forklifts Brand of engine: 1104C-44 Approved: Yes Yale Model: GDP50MG Model series: GDP50MG Model type: Forklifts Brand of engine: 1104C-44 Approved: Yes Yale Model: GDP55MG Model series: GDP55MG Model type: Forklifts Brand of engine: 1104C-44 Approved: Yes 1 / 43
-
