HC-Cargo Startmotor
HC-Cargo Startmotor
Artikelnr: F032111015

HC-Cargo Startmotor

Teknisk info:

Voltage: 12, kW: 1.1, No./teeth: 9, Rotation: CW

Beskrivning

Voltage: 12
kW: 1.1
Mount. flange: 76.20
Drive dist.: 15.00
Mount. hole 2 mm: 10.50
Mount. hole 1 mm: 10.50
Dist./back: 162.00
Dist./front: 47.00
No./teeth: 9
B+: M8
Position/B+: 60
Position/50: 15
Terminal 50: M5
Gear type: GR
Dist. mm: 105.00
Rotation: CW
Total length mm: 209.00
Clutch type: Dry
Drive type: Steel
Prod. info: BN
Waterproof: No
Oil sealed: No
No./mount. holes: 2 (0)

Filer

Specifikation

B+ M8
No./teeth 9
Mount. flange 76.20
Oil sealed No
No./mount. holes 2 (0)
Position/50 15
Clutch type Dry
Position/B+ 60
Prod. info BN
Rotation CW
Dist./back 162.00
Dist./front 47.00
Drive dist. 15.00
Drive type Steel
Gear type GR
kW 1.1
Terminal 50 M5
Voltage 12
Total length 209.00 mm
Waterproof No
Dist. 105.00 mm
Mount. hole 2 10.50 mm
Mount. hole 1 10.50 mm

  • OEM
    AZD2127, cs807, d6ra22, d6ra52, F032111015, 11.131.928, 1986S00656, 0001107033, 0001107051, 0001107062, 0001107085, 0001108129, 12850029, 12851306, 58101330, 58401330, 0058401940, 58401940, 63521070

  • Konkurrentreferens
    CST10171, CST15291, DRS8110, DRS9040, is1279, lrs01190, MS455, nd140, S0312, S3045, SBO0279, SR5034N, STR33001, 8EA015642-071, 8ea732894-001, 25-1225, 688.012.092, 688.013.092, 4141, 10807, 19668, 19669, 19669N, 19670, 19670N, 105586, 201028, 220087, 220087A, 455634, 594085, 726804, 838013, 8019040, 11019040, 063521070, 0986019040, 063521070620

  • Normaliserat artikelnummer
    azd2127, cs807, cst10171, cst15291, d6ra22, d6ra52, drs8110, drs9040, f032111015, is1279, lrs01190, ms455, nd140, s0312, s3045, sbo0279, sr5034n, str33001, 8ea015642071, 8ea732894001, 1986s00656, 4141, 10807, 19668, 19669, 19669n, 19670, 19670n, 105586, 201028, 220087, 220087a, 251225, 455634, 594085, 726804, 838013, 0001107033, 0001107051, 0001107062, 0001107085, 0001108129, 8019040, 11019040, 11131928, 12850029, 12851306, 58101330, 58401330, 0058401940, 58401940, 063521070, 63521070, 688012092, 688013092, 0986019040, 063521070620

  • Passar modeller
    Lombardini Model: Engine Model series: Various Models Approved: Yes
    Lombardini Model: Engine Model series: Various Models Size of motor: 0.5 Brand of engine: LDW502 From date: 01-06-1989 Fuel: Diesel Approved: Yes
    Lombardini Model: Engine Model series: Various Models Size of motor: 0.6 Brand of engine: LDW602 From date: 01-06-1989 Fuel: Diesel Approved: Yes
    Lombardini Model: Engine Model series: Various Models Size of motor: 0.9 Brand of engine: LDW903 From date: 01-06-1989 Fuel: Diesel Approved: Yes
    Lombardini Model: Engine Model series: Various Models Size of motor: 1.2 Brand of engine: LDW1204 From date: 01-06-1989 Fuel: Diesel Approved: Yes
    Various Agriculture Vehicles Model: Various Agriculture Vehicles Approved: Yes
    1 / 2
  • Beskrivning
    Voltage: 12
    kW: 1.1
    Mount. flange: 76.20
    Drive dist.: 15.00
    Mount. hole 2 mm: 10.50
    Mount. hole 1 mm: 10.50
    Dist./back: 162.00
    Dist./front: 47.00
    No./teeth: 9
    B+: M8
    Position/B+: 60
    Position/50: 15
    Terminal 50: M5
    Gear type: GR
    Dist. mm: 105.00
    Rotation: CW
    Total length mm: 209.00
    Clutch type: Dry
    Drive type: Steel
    Prod. info: BN
    Waterproof: No
    Oil sealed: No
    No./mount. holes: 2 (0)

    Filer

  • Specifikation
    B+ M8
    No./teeth 9
    Mount. flange 76.20
    Oil sealed No
    No./mount. holes 2 (0)
    Position/50 15
    Clutch type Dry
    Position/B+ 60
    Prod. info BN
    Rotation CW
    Dist./back 162.00
    Dist./front 47.00
    Drive dist. 15.00
    Drive type Steel
    Gear type GR
    kW 1.1
    Terminal 50 M5
    Voltage 12
    Total length 209.00 mm
    Waterproof No
    Dist. 105.00 mm
    Mount. hole 2 10.50 mm
    Mount. hole 1 10.50 mm
  • Fordonsmatchning

    • OEM
      AZD2127, cs807, d6ra22, d6ra52, F032111015, 11.131.928, 1986S00656, 0001107033, 0001107051, 0001107062, 0001107085, 0001108129, 12850029, 12851306, 58101330, 58401330, 0058401940, 58401940, 63521070

    • Konkurrentreferens
      CST10171, CST15291, DRS8110, DRS9040, is1279, lrs01190, MS455, nd140, S0312, S3045, SBO0279, SR5034N, STR33001, 8EA015642-071, 8ea732894-001, 25-1225, 688.012.092, 688.013.092, 4141, 10807, 19668, 19669, 19669N, 19670, 19670N, 105586, 201028, 220087, 220087A, 455634, 594085, 726804, 838013, 8019040, 11019040, 063521070, 0986019040, 063521070620

    • Normaliserat artikelnummer
      azd2127, cs807, cst10171, cst15291, d6ra22, d6ra52, drs8110, drs9040, f032111015, is1279, lrs01190, ms455, nd140, s0312, s3045, sbo0279, sr5034n, str33001, 8ea015642071, 8ea732894001, 1986s00656, 4141, 10807, 19668, 19669, 19669n, 19670, 19670n, 105586, 201028, 220087, 220087a, 251225, 455634, 594085, 726804, 838013, 0001107033, 0001107051, 0001107062, 0001107085, 0001108129, 8019040, 11019040, 11131928, 12850029, 12851306, 58101330, 58401330, 0058401940, 58401940, 063521070, 63521070, 688012092, 688013092, 0986019040, 063521070620

    • Passar modeller
      Lombardini Model: Engine Model series: Various Models Approved: Yes
      Lombardini Model: Engine Model series: Various Models Size of motor: 0.5 Brand of engine: LDW502 From date: 01-06-1989 Fuel: Diesel Approved: Yes
      Lombardini Model: Engine Model series: Various Models Size of motor: 0.6 Brand of engine: LDW602 From date: 01-06-1989 Fuel: Diesel Approved: Yes
      Lombardini Model: Engine Model series: Various Models Size of motor: 0.9 Brand of engine: LDW903 From date: 01-06-1989 Fuel: Diesel Approved: Yes
      Lombardini Model: Engine Model series: Various Models Size of motor: 1.2 Brand of engine: LDW1204 From date: 01-06-1989 Fuel: Diesel Approved: Yes
      Various Agriculture Vehicles Model: Various Agriculture Vehicles Approved: Yes
      1 / 2
