HC-Cargo Startmotor
HC-Cargo Startmotor
Artikelnr: F032110409

HC-Cargo Startmotor

Teknisk info:

Voltage: 12, kW: 3.0, No./teeth: 11, Rotation: CW

Beskrivning

Voltage: 12
kW: 3.0
Mount. flange: 89.00
Drive dist.: 47.00
Mount. hole 3 mm: 11.00
Mount. hole 2 mm: 11.00
Mount. hole 1 mm: 11.00
Dist./back: 318.50
Dist./front: 62.00
No./teeth: 11
B+: M10
Position/50: 60
Terminal 50: M6
Gear type: DD
Dist. 2: 90.50
Dist. 3: 90.50
Dist. mm: 127.50
Rotation: CW
Total length mm: 384.00
Drive type: Steel
Prod. info: BN
Waterproof: No
Oil sealed: No
No./mount. holes: 3 (0)

Filer

Specifikation

B+ M10
No./teeth 11
Mount. flange 89.00
Oil sealed No
No./mount. holes 3 (0)
Position/50 60
Prod. info BN
Dist. 2 90.50
Dist. 3 90.50
Rotation CW
Dist./back 318.50
Dist./front 62.00
Drive dist. 47.00
Drive type Steel
Gear type DD
kW 3.0
Terminal 50 M6
Voltage 12
Total length 384.00 mm
Waterproof No
Dist. 127.50 mm
Mount. hole 3 11.00 mm
Mount. hole 2 11.00 mm
Mount. hole 1 11.00 mm

  • OEM
    azk5487, bng4/12, C1R12X4H7622, C3R12X4H7622, F032110409, 11.139.140, 34/4, 81.26201-6019, 001170054, 01170054, 1170054, 01287138, 1287138, 0001400006, 0001400010, 0001401005, 0001401006, 0001401036, 0001401037, 0001401044, 0001401045, 0001401048, 0001413003, 0001418002, 02921436, 2921436, 19024001, 19024563, 0150442401, 605720100044

  • Konkurrentreferens
    MS584, S0834S, S0866S, 25-0018, 25-0125, 550.204.113

  • Normaliserat artikelnummer
    azk5487, bng412, c1r12x4h7622, c3r12x4h7622, f032110409, ms584, s0834s, s0866s, 344, 250018, 250125, 001170054, 01170054, 1170054, 01287138, 1287138, 0001400006, 0001400010, 0001401005, 0001401006, 0001401036, 0001401037, 0001401044, 0001401045, 0001401048, 0001413003, 0001418002, 02921436, 2921436, 11139140, 19024001, 19024563, 0150442401, 550204113, 81262016019, 605720100044

  • Passar modeller
    Kaelble Model: Various Models Model series: Various Models Approved: Yes
    Sennebogen Model: Various Models Model series: Various Models Approved: Yes
  • Beskrivning
    Voltage: 12
    kW: 3.0
    Mount. flange: 89.00
    Drive dist.: 47.00
    Mount. hole 3 mm: 11.00
    Mount. hole 2 mm: 11.00
    Mount. hole 1 mm: 11.00
    Dist./back: 318.50
    Dist./front: 62.00
    No./teeth: 11
    B+: M10
    Position/50: 60
    Terminal 50: M6
    Gear type: DD
    Dist. 2: 90.50
    Dist. 3: 90.50
    Dist. mm: 127.50
    Rotation: CW
    Total length mm: 384.00
    Drive type: Steel
    Prod. info: BN
    Waterproof: No
    Oil sealed: No
    No./mount. holes: 3 (0)

    Filer

  • Specifikation
    B+ M10
    No./teeth 11
    Mount. flange 89.00
    Oil sealed No
    No./mount. holes 3 (0)
    Position/50 60
    Prod. info BN
    Dist. 2 90.50
    Dist. 3 90.50
    Rotation CW
    Dist./back 318.50
    Dist./front 62.00
    Drive dist. 47.00
    Drive type Steel
    Gear type DD
    kW 3.0
    Terminal 50 M6
    Voltage 12
    Total length 384.00 mm
    Waterproof No
    Dist. 127.50 mm
    Mount. hole 3 11.00 mm
    Mount. hole 2 11.00 mm
    Mount. hole 1 11.00 mm
  • Fordonsmatchning

    • OEM
      azk5487, bng4/12, C1R12X4H7622, C3R12X4H7622, F032110409, 11.139.140, 34/4, 81.26201-6019, 001170054, 01170054, 1170054, 01287138, 1287138, 0001400006, 0001400010, 0001401005, 0001401006, 0001401036, 0001401037, 0001401044, 0001401045, 0001401048, 0001413003, 0001418002, 02921436, 2921436, 19024001, 19024563, 0150442401, 605720100044

    • Konkurrentreferens
      MS584, S0834S, S0866S, 25-0018, 25-0125, 550.204.113

    • Normaliserat artikelnummer
      azk5487, bng412, c1r12x4h7622, c3r12x4h7622, f032110409, ms584, s0834s, s0866s, 344, 250018, 250125, 001170054, 01170054, 1170054, 01287138, 1287138, 0001400006, 0001400010, 0001401005, 0001401006, 0001401036, 0001401037, 0001401044, 0001401045, 0001401048, 0001413003, 0001418002, 02921436, 2921436, 11139140, 19024001, 19024563, 0150442401, 550204113, 81262016019, 605720100044

    • Passar modeller
      Kaelble Model: Various Models Model series: Various Models Approved: Yes
      Sennebogen Model: Various Models Model series: Various Models Approved: Yes
