HC-Cargo Startmotor
HC-Cargo Startmotor
Artikelnr: F032114173

HC-Cargo Startmotor

Teknisk info:

Voltage: 12, kW: 1.7, No./teeth: 10, Rotation: CCW

Beskrivning

VW Caddy Startm. 12V-1.7kW 12V - 1.7kW, 10k, CCW A - 76mm, B - 57 För Yourex produkt order 91-620-2032

Voltage: 12
kW: 1.7
Mount. flange: 76.00
Drive dist.: 58.00
Mount. hole 2 mm: 11.00
Mount. hole 1 mm: 11.00
Dist./back: 168.00
Dist./front: 63.00
No./teeth: 10
B+: M8
Position/50: 15
Terminal 50: Plug
Gear type: GR
Dist. mm: 111.00
Rotation: CCW
Total length mm: 244.00
Clutch type: Dry
Drive type: Steel
No./mount. holes: 2 (0)

Filer

Specifikation

B+ M8
No./teeth 10
Mount. flange 76.00
No./mount. holes 2 (0)
Position/50 15
Clutch type Dry
Rotation CCW
Dist./back 168.00
Dist./front 63.00
Drive dist. 58.00
Drive type Steel
Gear type GR
kW 1.7
Terminal 50 Plug
Voltage 12
Total length 244.00 mm
Dist. 111.00 mm
Mount. hole 2 11.00 mm
Mount. hole 1 11.00 mm

  • OEM
    0AH 911 023B, 0AH911023B, 0AH911023BX, cs1397, F032114173, RGO 114173, 0001 123 020, 0001 123 021, 0986 020 320, 1986S00800, 114173, 0001123020, 0001123021

  • Konkurrentreferens
    CST10445, DRT0320, DRT0320X, F042S0H096, LRS02473, S0229, S0229PR, STR-H096, 8EA012528-051, 25-4145, 311.264.102, 3043, 32688N, 101397, 105510, 458875, 8213300, 11020320, 0986020320

  • Bilmärken
    VW

  • Normaliserat artikelnummer
    0ah911023b, 0ah911023bx, cs1397, cst10445, drt0320, drt0320x, f032114173, f042s0h096, lrs02473, rgo114173, s0229, s0229pr, strh096, 8ea012528051, 1986s00800, 3043, 32688n, 101397, 105510, 114173, 254145, 458875, 0001123020, 0001123021, 8213300, 11020320, 311264102, 0986020320

  • Passar modeller
    VW Model: Caddy Model series: Caddy Type of engine: SDi Size of motor: 2.0 Brand of engine: BDJ Type description: 2KA, 2KH Body: Van From date: 01-03-2004 To date: 01-08-2010 Fuel: Diesel Approved: Yes
    VW Model: Caddy Model series: Caddy Type of engine: SDi Size of motor: 2.0 Brand of engine: BDJ Type description: 2KB, 2KJ Body: Estate From date: 01-03-2004 To date: 01-08-2010 Fuel: Diesel Approved: Yes
    VW Model: Caddy Model series: Caddy Type of engine: SDi Size of motor: 2.0 Brand of engine: BST Type description: 2KA, 2KH Body: Van From date: 01-03-2004 To date: 01-08-2010 Fuel: Diesel Approved: Yes
    VW Model: Caddy Model series: Caddy Type of engine: SDi Size of motor: 2.0 Brand of engine: BST Type description: 2KB, 2KJ Body: Estate From date: 01-03-2004 To date: 01-08-2010 Fuel: Diesel Approved: Yes
    VW Series: Caddy III Skåp (2K_) Model: 2.0 SDI Skåp Engine volume: 2.0 Engine type: BDJ / BST Year: 03.04-05.08
    VW Series: Caddy III Variant Model: 2.0 SDI Engine volume: 2.0 Engine type: BDJ / BST Year: 03.04-05.08
    VW Series: Caddy III Variant Model: 2.0 SDI Engine volume: 2.0 Engine type: BDJ / BST Year: 06.05-05.08
    1 / 2
  • Beskrivning
    VW Caddy Startm. 12V-1.7kW 12V - 1.7kW, 10k, CCW A - 76mm, B - 57 För Yourex produkt order 91-620-2032

    Voltage: 12
    kW: 1.7
    Mount. flange: 76.00
    Drive dist.: 58.00
    Mount. hole 2 mm: 11.00
    Mount. hole 1 mm: 11.00
    Dist./back: 168.00
    Dist./front: 63.00
    No./teeth: 10
    B+: M8
    Position/50: 15
    Terminal 50: Plug
    Gear type: GR
    Dist. mm: 111.00
    Rotation: CCW
    Total length mm: 244.00
    Clutch type: Dry
    Drive type: Steel
    No./mount. holes: 2 (0)

    Filer

  • Specifikation
    B+ M8
    No./teeth 10
    Mount. flange 76.00
    No./mount. holes 2 (0)
    Position/50 15
    Clutch type Dry
    Rotation CCW
    Dist./back 168.00
    Dist./front 63.00
    Drive dist. 58.00
    Drive type Steel
    Gear type GR
    kW 1.7
    Terminal 50 Plug
    Voltage 12
    Total length 244.00 mm
    Dist. 111.00 mm
    Mount. hole 2 11.00 mm
    Mount. hole 1 11.00 mm
  • Fordonsmatchning

    • OEM
      0AH 911 023B, 0AH911023B, 0AH911023BX, cs1397, F032114173, RGO 114173, 0001 123 020, 0001 123 021, 0986 020 320, 1986S00800, 114173, 0001123020, 0001123021

    • Konkurrentreferens
      CST10445, DRT0320, DRT0320X, F042S0H096, LRS02473, S0229, S0229PR, STR-H096, 8EA012528-051, 25-4145, 311.264.102, 3043, 32688N, 101397, 105510, 458875, 8213300, 11020320, 0986020320

    • Bilmärken
      VW

    • Normaliserat artikelnummer
      0ah911023b, 0ah911023bx, cs1397, cst10445, drt0320, drt0320x, f032114173, f042s0h096, lrs02473, rgo114173, s0229, s0229pr, strh096, 8ea012528051, 1986s00800, 3043, 32688n, 101397, 105510, 114173, 254145, 458875, 0001123020, 0001123021, 8213300, 11020320, 311264102, 0986020320

    • Passar modeller
      VW Model: Caddy Model series: Caddy Type of engine: SDi Size of motor: 2.0 Brand of engine: BDJ Type description: 2KA, 2KH Body: Van From date: 01-03-2004 To date: 01-08-2010 Fuel: Diesel Approved: Yes
      VW Model: Caddy Model series: Caddy Type of engine: SDi Size of motor: 2.0 Brand of engine: BDJ Type description: 2KB, 2KJ Body: Estate From date: 01-03-2004 To date: 01-08-2010 Fuel: Diesel Approved: Yes
      VW Model: Caddy Model series: Caddy Type of engine: SDi Size of motor: 2.0 Brand of engine: BST Type description: 2KA, 2KH Body: Van From date: 01-03-2004 To date: 01-08-2010 Fuel: Diesel Approved: Yes
      VW Model: Caddy Model series: Caddy Type of engine: SDi Size of motor: 2.0 Brand of engine: BST Type description: 2KB, 2KJ Body: Estate From date: 01-03-2004 To date: 01-08-2010 Fuel: Diesel Approved: Yes
      VW Series: Caddy III Skåp (2K_) Model: 2.0 SDI Skåp Engine volume: 2.0 Engine type: BDJ / BST Year: 03.04-05.08
      VW Series: Caddy III Variant Model: 2.0 SDI Engine volume: 2.0 Engine type: BDJ / BST Year: 03.04-05.08
      VW Series: Caddy III Variant Model: 2.0 SDI Engine volume: 2.0 Engine type: BDJ / BST Year: 06.05-05.08
      1 / 2
