HC-Cargo Generator
HC-Cargo Generator
Artikelnr: F032113063

HC-Cargo Generator

Teknisk info:

Voltage: 14, Amp: 90, Rotation: CW, Mount. bracket dist.: 54.00

Beskrivning

Voltage: 14
Amp: 90
Pulley dist.: 34.00
Width/holder arm: 14.30
Mount. bracket dist.: 54.00
Bracket hole: 10.50
Belt. adj. brackethole pos.: 60
Belt. adj. bracket hole 1: 11.70
Pulley dia.: 57.20
Grooves/pulley: 6
Radius: 96.00
Radius 2: 87.00
B+: M6
Position/B+ in min.: 20
Rotation: CW
Total length mm: 185.00
Pulley: SP
Prod. info: BN
Servicing: Dodge

Filer

Specifikation

B+ M6
Mount. bracket dist. 54.00
Belt. adj. bracket hole 1 11.70
Belt. adj. brackethole pos. 60
Bracket hole 10.50
Position/B+ in min. 20
Prod. info BN
Pulley SP
Pulley dia. 57.20
Pulley dist. 34.00
Radius 96.00
Radius 2 87.00
Rotation CW
Servicing Dodge
Grooves/pulley 6
Voltage 14
Total length 185.00 mm
Width/holder arm 14.30
Amp 90

  • OEM
    F032113063, 121000-3450, 121000-3452, 56005685, 56005685ab, 59005685

  • Konkurrentreferens
    a1405, a1598n, A6614S, ALT-5066, ALT5066, and0023, az-0019r, CAL40272, da13341, DRA3788, F042302057, F042A02057, lrb00239, 1-1511-01nd, 13-8613, 27-3603, 90-29-5122, 534.003.902, 13199, 13341, 32118507

  • Normaliserat artikelnummer
    a1405, a1598n, a6614s, alt5066, and0023, az0019r, cal40272, da13341, dra3788, f032113063, f042302057, f042a02057, lrb00239, 13199, 13341, 138613, 273603, 1151101nd, 32118507, 56005685, 56005685ab, 59005685, 90295122, 534003902, 1210003450, 1210003452

  • Passar modeller
    Dodge Model: Dakota Model series: Dakota Size of motor: 2.5 From date: 01-01-1997 To date: 01-01-1997 Fuel: Gasoline Approved: Yes
    Dodge Model: Dakota Model series: Dakota Size of motor: 2.5 From date: 01-01-1998 To date: 01-01-1998 Fuel: Gasoline Approved: Yes
    Jeep Model: Cherokee Model series: Cherokee Model type: 4x4 Size of motor: 2.5 Brand of engine: EPE Type description: XJ Body: Closed Off-Road Vehicle From date: 01-10-1990 To date: 01-09-1996 Fuel: Petrol Approved: Yes
    Jeep Model: Cherokee Model series: Cherokee Model type: Briarwood Size of motor: 4.0 From date: 01-01-1991 To date: 01-01-1992 Fuel: Gasoline Approved: Yes
    Jeep Model: Cherokee Model series: Cherokee Model type: Country Size of motor: 4.0 From date: 01-01-1993 To date: 01-01-1996 Fuel: Gasoline Approved: Yes
    Jeep Model: Cherokee Model series: Cherokee Model type: Country Size of motor: 4.0 From date: 01-01-1997 To date: 01-01-1997 Fuel: Gasoline Approved: Yes
    Jeep Model: Cherokee Model series: Cherokee Model type: Laredo Size of motor: 4.0 From date: 01-01-1991 To date: 01-01-1992 Fuel: Gasoline Approved: Yes
    Jeep Model: Cherokee Model series: Cherokee Model type: Limited Size of motor: 4.0 From date: 01-01-1991 To date: 01-01-1992 Fuel: Gasoline Approved: Yes
    Jeep Model: Cherokee Model series: Cherokee Model type: SE Size of motor: 2.5 From date: 01-01-1994 To date: 01-01-1997 Fuel: Gasoline Approved: Yes
    Jeep Model: Cherokee Model series: Cherokee Model type: SE Size of motor: 4.0 From date: 01-01-1994 To date: 01-01-1997 Fuel: Gasoline Approved: Yes
    Jeep Model: Cherokee Model series: Cherokee Model type: Sport Size of motor: 4.0 From date: 01-01-1991 To date: 01-01-1996 Fuel: Gasoline Approved: Yes
    Jeep Model: Cherokee Model series: Cherokee Model type: Sport Size of motor: 4.0 From date: 01-01-1997 To date: 01-01-1997 Fuel: Gasoline Approved: Yes
    Jeep Model: Cherokee Model series: Cherokee Size of motor: 2.5 From date: 01-01-1991 To date: 01-01-1993 Fuel: Gasoline Approved: Yes
    Jeep Model: Cherokee Model series: Cherokee Size of motor: 2.5 From date: 01-01-1998 To date: 01-01-1998 Fuel: Gasoline Approved: Yes
    Jeep Model: Cherokee Model series: Cherokee Size of motor: 4.0 From date: 01-01-1991 To date: 01-01-1993 Fuel: Gasoline Approved: Yes
    Jeep Model: Cherokee Model series: Cherokee Size of motor: 4.0 From date: 01-01-1996 To date: 01-01-1996 Fuel: Gasoline Approved: Yes Manufacture type: Classic
    Jeep Model: Cherokee Model series: Cherokee Size of motor: 4.0 From date: 01-01-1998 To date: 01-01-1998 Fuel: Gasoline Approved: Yes
    Jeep Model: Comanche Model series: Comanche Model type: Eliminator Size of motor: 4.0 From date: 01-01-1991 To date: 01-01-1992 Fuel: Gasoline Approved: Yes
    Jeep Model: Comanche Model series: Comanche Model type: Pioneer Size of motor: 2.5 From date: 01-01-1991 To date: 01-01-1991 Fuel: Gasoline Approved: Yes
    Jeep Model: Comanche Model series: Comanche Model type: Pioneer Size of motor: 4.0 From date: 01-01-1991 To date: 01-01-1992 Fuel: Gasoline Approved: Yes
    Jeep Model: Comanche Model series: Comanche Size of motor: 2.5 From date: 01-01-1991 To date: 01-01-1992 Fuel: Gasoline Approved: Yes
    Jeep Model: Comanche Model series: Comanche Size of motor: 4.0 From date: 01-01-1991 To date: 01-01-1992 Fuel: Gasoline Approved: Yes
    Jeep Model: Grand Cherokee Model series: Grand Cherokee Model type: 4x4 Size of motor: 4.0 Brand of engine: ERH Type description: ZJ, ZG Body: Closed Off-Road Vehicle From date: 01-09-1992 To date: 01-12-1994 Fuel: Petrol Approved: Yes
    Jeep Model: Grand Cherokee Model series: Grand Cherokee Model type: Laredo Size of motor: 4.0 From date: 01-01-1993 To date: 01-01-1997 Fuel: Gasoline Approved: Yes
    Jeep Model: Grand Cherokee Model series: Grand Cherokee Model type: Laredo Size of motor: 4.0 From date: 01-01-1998 To date: 01-01-1998 Fuel: Gasoline Approved: Yes
    Jeep Model: Grand Cherokee Model series: Grand Cherokee Model type: Limited Size of motor: 4.0 From date: 01-01-1993 To date: 01-01-1997 Fuel: Gasoline Approved: Yes
    Jeep Model: Grand Cherokee Model series: Grand Cherokee Model type: Limited Size of motor: 4.0 From date: 01-01-1998 To date: 01-01-1998 Fuel: Gasoline Approved: Yes
    Jeep Model: Grand Cherokee Model series: Grand Cherokee Model type: Orvis Size of motor: 4.0 From date: 01-01-1995 To date: 01-01-1997 Fuel: Gasoline Approved: Yes
    Jeep Model: Grand Cherokee Model series: Grand Cherokee Model type: SE Size of motor: 4.0 From date: 01-01-1994 To date: 01-01-1995 Fuel: Gasoline Approved: Yes
    Jeep Model: Grand Cherokee Model series: Grand Cherokee Size of motor: 4.0 From date: 01-01-1993 To date: 01-01-1993 Fuel: Gasoline Approved: Yes
    Jeep Model: Wagoneer Model series: Wagoneer Model type: Islander Size of motor: 2.5 From date: 01-01-1991 To date: 01-01-1991 Fuel: Gasoline Approved: Yes
    Jeep Model: Wagoneer Model series: Wagoneer Model type: Islander Size of motor: 4.0 From date: 01-01-1991 To date: 01-01-1992 Fuel: Gasoline Approved: Yes
    Jeep Model: Wagoneer Model series: Wagoneer Model type: Renegade Size of motor: 4.0 From date: 01-01-1991 To date: 01-01-1994 Fuel: Gasoline Approved: Yes
    Jeep Model: Wagoneer Model series: Wagoneer Model type: Rio Grande Size of motor: 2.5 From date: 01-01-1995 To date: 01-01-1995 Fuel: Gasoline Approved: Yes
    Jeep Model: Wagoneer Model series: Wagoneer Model type: S Size of motor: 2.5 From date: 01-01-1991 To date: 01-01-1994 Fuel: Gasoline Approved: Yes
    Jeep Model: Wagoneer Model series: Wagoneer Model type: S Size of motor: 4.0 From date: 01-01-1992 To date: 01-01-1992 Fuel: Gasoline Approved: Yes
    Jeep Model: Wagoneer Model series: Wagoneer Model type: Sahara Size of motor: 2.5 From date: 01-01-1991 To date: 01-01-1991 Fuel: Gasoline Approved: Yes
    Jeep Model: Wagoneer Model series: Wagoneer Model type: Sahara Size of motor: 4.0 From date: 01-01-1991 To date: 01-01-1997 Fuel: Gasoline Approved: Yes
    Jeep Model: Wagoneer Model series: Wagoneer Model type: SE Size of motor: 2.5 From date: 01-01-1994 To date: 01-01-1997 Fuel: Gasoline Approved: Yes
    Jeep Model: Wagoneer Model series: Wagoneer Model type: SE Size of motor: 4.0 From date: 01-01-1994 To date: 01-01-1995 Fuel: Gasoline Approved: Yes
    Jeep Model: Wagoneer Model series: Wagoneer Model type: Sport Size of motor: 4.0 From date: 01-01-1997 To date: 01-01-1997 Fuel: Gasoline Approved: Yes
    Jeep Model: Wagoneer Model series: Wagoneer Size of motor: 2.5 From date: 01-01-1991 To date: 01-01-1993 Fuel: Gasoline Approved: Yes
    Jeep Model: Wagoneer Model series: Wagoneer Size of motor: 4.0 From date: 01-01-1991 To date: 01-01-1993 Fuel: Gasoline Approved: Yes
    Jeep Model: Wrangler Model series: Wrangler Model type: 4x4 Size of motor: 4.0 Brand of engine: ERH Type description: TJ Body: Open Off-Road Vehicle From date: 01-01-1997 To date: 01-12-2007 Fuel: Petrol Approved: Yes
    Jeep Model: Wrangler Model series: Wrangler Size of motor: 2.5 From date: 01-01-1998 To date: 01-01-1998 Fuel: Gasoline Approved: Yes
    Jeep Model: Wrangler Model series: Wrangler Size of motor: 4.0 From date: 01-01-1998 To date: 01-01-1998 Fuel: Gasoline Approved: Yes
    1 / 10
  • Beskrivning
    Voltage: 14
    Amp: 90
    Pulley dist.: 34.00
    Width/holder arm: 14.30
    Mount. bracket dist.: 54.00
    Bracket hole: 10.50
    Belt. adj. brackethole pos.: 60
    Belt. adj. bracket hole 1: 11.70
    Pulley dia.: 57.20
    Grooves/pulley: 6
    Radius: 96.00
    Radius 2: 87.00
    B+: M6
    Position/B+ in min.: 20
    Rotation: CW
    Total length mm: 185.00
    Pulley: SP
    Prod. info: BN
    Servicing: Dodge

    Filer

  • Specifikation
    B+ M6
    Mount. bracket dist. 54.00
    Belt. adj. bracket hole 1 11.70
    Belt. adj. brackethole pos. 60
    Bracket hole 10.50
    Position/B+ in min. 20
    Prod. info BN
    Pulley SP
    Pulley dia. 57.20
    Pulley dist. 34.00
    Radius 96.00
    Radius 2 87.00
    Rotation CW
    Servicing Dodge
    Grooves/pulley 6
    Voltage 14
    Total length 185.00 mm
    Width/holder arm 14.30
    Amp 90
  • Fordonsmatchning

    • OEM
      F032113063, 121000-3450, 121000-3452, 56005685, 56005685ab, 59005685

    • Konkurrentreferens
      a1405, a1598n, A6614S, ALT-5066, ALT5066, and0023, az-0019r, CAL40272, da13341, DRA3788, F042302057, F042A02057, lrb00239, 1-1511-01nd, 13-8613, 27-3603, 90-29-5122, 534.003.902, 13199, 13341, 32118507

    • Normaliserat artikelnummer
      a1405, a1598n, a6614s, alt5066, and0023, az0019r, cal40272, da13341, dra3788, f032113063, f042302057, f042a02057, lrb00239, 13199, 13341, 138613, 273603, 1151101nd, 32118507, 56005685, 56005685ab, 59005685, 90295122, 534003902, 1210003450, 1210003452

    • Passar modeller
      Dodge Model: Dakota Model series: Dakota Size of motor: 2.5 From date: 01-01-1997 To date: 01-01-1997 Fuel: Gasoline Approved: Yes
      Dodge Model: Dakota Model series: Dakota Size of motor: 2.5 From date: 01-01-1998 To date: 01-01-1998 Fuel: Gasoline Approved: Yes
      Jeep Model: Cherokee Model series: Cherokee Model type: 4x4 Size of motor: 2.5 Brand of engine: EPE Type description: XJ Body: Closed Off-Road Vehicle From date: 01-10-1990 To date: 01-09-1996 Fuel: Petrol Approved: Yes
      Jeep Model: Cherokee Model series: Cherokee Model type: Briarwood Size of motor: 4.0 From date: 01-01-1991 To date: 01-01-1992 Fuel: Gasoline Approved: Yes
      Jeep Model: Cherokee Model series: Cherokee Model type: Country Size of motor: 4.0 From date: 01-01-1993 To date: 01-01-1996 Fuel: Gasoline Approved: Yes
      Jeep Model: Cherokee Model series: Cherokee Model type: Country Size of motor: 4.0 From date: 01-01-1997 To date: 01-01-1997 Fuel: Gasoline Approved: Yes
      Jeep Model: Cherokee Model series: Cherokee Model type: Laredo Size of motor: 4.0 From date: 01-01-1991 To date: 01-01-1992 Fuel: Gasoline Approved: Yes
      Jeep Model: Cherokee Model series: Cherokee Model type: Limited Size of motor: 4.0 From date: 01-01-1991 To date: 01-01-1992 Fuel: Gasoline Approved: Yes
      Jeep Model: Cherokee Model series: Cherokee Model type: SE Size of motor: 2.5 From date: 01-01-1994 To date: 01-01-1997 Fuel: Gasoline Approved: Yes
      Jeep Model: Cherokee Model series: Cherokee Model type: SE Size of motor: 4.0 From date: 01-01-1994 To date: 01-01-1997 Fuel: Gasoline Approved: Yes
      Jeep Model: Cherokee Model series: Cherokee Model type: Sport Size of motor: 4.0 From date: 01-01-1991 To date: 01-01-1996 Fuel: Gasoline Approved: Yes
      Jeep Model: Cherokee Model series: Cherokee Model type: Sport Size of motor: 4.0 From date: 01-01-1997 To date: 01-01-1997 Fuel: Gasoline Approved: Yes
      Jeep Model: Cherokee Model series: Cherokee Size of motor: 2.5 From date: 01-01-1991 To date: 01-01-1993 Fuel: Gasoline Approved: Yes
      Jeep Model: Cherokee Model series: Cherokee Size of motor: 2.5 From date: 01-01-1998 To date: 01-01-1998 Fuel: Gasoline Approved: Yes
      Jeep Model: Cherokee Model series: Cherokee Size of motor: 4.0 From date: 01-01-1991 To date: 01-01-1993 Fuel: Gasoline Approved: Yes
      Jeep Model: Cherokee Model series: Cherokee Size of motor: 4.0 From date: 01-01-1996 To date: 01-01-1996 Fuel: Gasoline Approved: Yes Manufacture type: Classic
      Jeep Model: Cherokee Model series: Cherokee Size of motor: 4.0 From date: 01-01-1998 To date: 01-01-1998 Fuel: Gasoline Approved: Yes
      Jeep Model: Comanche Model series: Comanche Model type: Eliminator Size of motor: 4.0 From date: 01-01-1991 To date: 01-01-1992 Fuel: Gasoline Approved: Yes
      Jeep Model: Comanche Model series: Comanche Model type: Pioneer Size of motor: 2.5 From date: 01-01-1991 To date: 01-01-1991 Fuel: Gasoline Approved: Yes
      Jeep Model: Comanche Model series: Comanche Model type: Pioneer Size of motor: 4.0 From date: 01-01-1991 To date: 01-01-1992 Fuel: Gasoline Approved: Yes
      Jeep Model: Comanche Model series: Comanche Size of motor: 2.5 From date: 01-01-1991 To date: 01-01-1992 Fuel: Gasoline Approved: Yes
      Jeep Model: Comanche Model series: Comanche Size of motor: 4.0 From date: 01-01-1991 To date: 01-01-1992 Fuel: Gasoline Approved: Yes
      Jeep Model: Grand Cherokee Model series: Grand Cherokee Model type: 4x4 Size of motor: 4.0 Brand of engine: ERH Type description: ZJ, ZG Body: Closed Off-Road Vehicle From date: 01-09-1992 To date: 01-12-1994 Fuel: Petrol Approved: Yes
      Jeep Model: Grand Cherokee Model series: Grand Cherokee Model type: Laredo Size of motor: 4.0 From date: 01-01-1993 To date: 01-01-1997 Fuel: Gasoline Approved: Yes
      Jeep Model: Grand Cherokee Model series: Grand Cherokee Model type: Laredo Size of motor: 4.0 From date: 01-01-1998 To date: 01-01-1998 Fuel: Gasoline Approved: Yes
      Jeep Model: Grand Cherokee Model series: Grand Cherokee Model type: Limited Size of motor: 4.0 From date: 01-01-1993 To date: 01-01-1997 Fuel: Gasoline Approved: Yes
      Jeep Model: Grand Cherokee Model series: Grand Cherokee Model type: Limited Size of motor: 4.0 From date: 01-01-1998 To date: 01-01-1998 Fuel: Gasoline Approved: Yes
      Jeep Model: Grand Cherokee Model series: Grand Cherokee Model type: Orvis Size of motor: 4.0 From date: 01-01-1995 To date: 01-01-1997 Fuel: Gasoline Approved: Yes
      Jeep Model: Grand Cherokee Model series: Grand Cherokee Model type: SE Size of motor: 4.0 From date: 01-01-1994 To date: 01-01-1995 Fuel: Gasoline Approved: Yes
      Jeep Model: Grand Cherokee Model series: Grand Cherokee Size of motor: 4.0 From date: 01-01-1993 To date: 01-01-1993 Fuel: Gasoline Approved: Yes
      Jeep Model: Wagoneer Model series: Wagoneer Model type: Islander Size of motor: 2.5 From date: 01-01-1991 To date: 01-01-1991 Fuel: Gasoline Approved: Yes
      Jeep Model: Wagoneer Model series: Wagoneer Model type: Islander Size of motor: 4.0 From date: 01-01-1991 To date: 01-01-1992 Fuel: Gasoline Approved: Yes
      Jeep Model: Wagoneer Model series: Wagoneer Model type: Renegade Size of motor: 4.0 From date: 01-01-1991 To date: 01-01-1994 Fuel: Gasoline Approved: Yes
      Jeep Model: Wagoneer Model series: Wagoneer Model type: Rio Grande Size of motor: 2.5 From date: 01-01-1995 To date: 01-01-1995 Fuel: Gasoline Approved: Yes
      Jeep Model: Wagoneer Model series: Wagoneer Model type: S Size of motor: 2.5 From date: 01-01-1991 To date: 01-01-1994 Fuel: Gasoline Approved: Yes
      Jeep Model: Wagoneer Model series: Wagoneer Model type: S Size of motor: 4.0 From date: 01-01-1992 To date: 01-01-1992 Fuel: Gasoline Approved: Yes
      Jeep Model: Wagoneer Model series: Wagoneer Model type: Sahara Size of motor: 2.5 From date: 01-01-1991 To date: 01-01-1991 Fuel: Gasoline Approved: Yes
      Jeep Model: Wagoneer Model series: Wagoneer Model type: Sahara Size of motor: 4.0 From date: 01-01-1991 To date: 01-01-1997 Fuel: Gasoline Approved: Yes
      Jeep Model: Wagoneer Model series: Wagoneer Model type: SE Size of motor: 2.5 From date: 01-01-1994 To date: 01-01-1997 Fuel: Gasoline Approved: Yes
      Jeep Model: Wagoneer Model series: Wagoneer Model type: SE Size of motor: 4.0 From date: 01-01-1994 To date: 01-01-1995 Fuel: Gasoline Approved: Yes
      Jeep Model: Wagoneer Model series: Wagoneer Model type: Sport Size of motor: 4.0 From date: 01-01-1997 To date: 01-01-1997 Fuel: Gasoline Approved: Yes
      Jeep Model: Wagoneer Model series: Wagoneer Size of motor: 2.5 From date: 01-01-1991 To date: 01-01-1993 Fuel: Gasoline Approved: Yes
      Jeep Model: Wagoneer Model series: Wagoneer Size of motor: 4.0 From date: 01-01-1991 To date: 01-01-1993 Fuel: Gasoline Approved: Yes
      Jeep Model: Wrangler Model series: Wrangler Model type: 4x4 Size of motor: 4.0 Brand of engine: ERH Type description: TJ Body: Open Off-Road Vehicle From date: 01-01-1997 To date: 01-12-2007 Fuel: Petrol Approved: Yes
      Jeep Model: Wrangler Model series: Wrangler Size of motor: 2.5 From date: 01-01-1998 To date: 01-01-1998 Fuel: Gasoline Approved: Yes
      Jeep Model: Wrangler Model series: Wrangler Size of motor: 4.0 From date: 01-01-1998 To date: 01-01-1998 Fuel: Gasoline Approved: Yes
