HC-Cargo Generator
HC-Cargo Generator
Artikelnr: F032110497

HC-Cargo Generator

Teknisk info:

Voltage: 14, Amp: 70, Rotation: CW, Mount. bracket dist.: 84.00

Beskrivning

Voltage: 14
Amp: 70
Terminal: W
Pulley dist.: 42.50
Width/holder arm: 10.50
Mount. bracket dist.: 84.00
Bracket hole: 10.00
Belt. adj. brackethole pos.: 55
Belt. adj. brackethole pos. 3: 5
Belt. adj. brackethole pos. 2: 60
Belt. adj. bracket hole 1: 8.00
Pulley dia.: 73.00
Grooves/pulley: 1
Radius: 83.50
Radius 2: 82.50
Radius 3: 82.50
Radius 4: 82.50
B+: 9.40
Position/B+ in min.: 20
D+ Size: 6.30
Rotation: CW
Plug no.: PL22
W plug type: M5
Total length mm: 166.00
Pulley: P
Regulator type: IR
Prod. info: BN
Servicing: Austin-Healey

Filer

Specifikation

B+ 9.40
Mount. bracket dist. 84.00
Belt. adj. bracket hole 1 8.00
Belt. adj. brackethole pos. 55
Belt. adj. brackethole pos. 2 60
Belt. adj. brackethole pos. 3 5
Plug no. PL22
Bracket hole 10.00
Position/B+ in min. 20
Prod. info BN
Pulley P
Pulley dia. 73.00
Pulley dist. 42.50
Radius 83.50
D+ Size 6.30
Radius 2 82.50
Radius 3 82.50
Radius 4 82.50
Regulator type IR
Rotation CW
Servicing Austin-Healey
Grooves/pulley 1
Terminal W
Voltage 14
W plug type M5
Total length 166.00 mm
Width/holder arm 10.50
Amp 70

  • OEM
    F032110497, nab900, 1457ir, 66021070, 66021155, 66921126, 9120690170

  • Konkurrentreferens
    A4036, ALT-4036, ALT16000, ALT4036, BAO3211, CAL11108, F042306030, F042A06030, 8el737662-001, 015.002.065, 28-8626, 5764, 12750N, 209248, 209248A, 301457RI, 301550RI, 66021126, 66021126K

  • Normaliserat artikelnummer
    a4036, alt16000, alt4036, bao3211, cal11108, f032110497, f042306030, f042a06030, nab900, 8el737662001, 1457ir, 5764, 12750n, 209248, 209248a, 288626, 301457ri, 301550ri, 015002065, 66021070, 66021126, 66021126k, 66021155, 66921126, 9120690170

  • Passar modeller
    Austin-Healey Model: Sprite Model series: Sprite MK Size of motor: 1.1 Brand of engine: 10CG-D-A Type description: Mk lll Body: Convertible From date: 01-03-1964 To date: 01-09-1966 Fuel: Gasoline Approved: Yes
    Austin-Healey Model: Sprite Model series: Sprite MK Size of motor: 1.3 Brand of engine: 10CG-D-A Type description: Mk lllA Body: Convertible From date: 01-03-1966 To date: 01-10-1971 Fuel: Gasoline Approved: Yes
    Various Agriculture Vehicles Model: Various Agriculture Vehicles Approved: Yes
  • Beskrivning
    Voltage: 14
    Amp: 70
    Terminal: W
    Pulley dist.: 42.50
    Width/holder arm: 10.50
    Mount. bracket dist.: 84.00
    Bracket hole: 10.00
    Belt. adj. brackethole pos.: 55
    Belt. adj. brackethole pos. 3: 5
    Belt. adj. brackethole pos. 2: 60
    Belt. adj. bracket hole 1: 8.00
    Pulley dia.: 73.00
    Grooves/pulley: 1
    Radius: 83.50
    Radius 2: 82.50
    Radius 3: 82.50
    Radius 4: 82.50
    B+: 9.40
    Position/B+ in min.: 20
    D+ Size: 6.30
    Rotation: CW
    Plug no.: PL22
    W plug type: M5
    Total length mm: 166.00
    Pulley: P
    Regulator type: IR
    Prod. info: BN
    Servicing: Austin-Healey

    Filer

  • Specifikation
    B+ 9.40
    Mount. bracket dist. 84.00
    Belt. adj. bracket hole 1 8.00
    Belt. adj. brackethole pos. 55
    Belt. adj. brackethole pos. 2 60
    Belt. adj. brackethole pos. 3 5
    Plug no. PL22
    Bracket hole 10.00
    Position/B+ in min. 20
    Prod. info BN
    Pulley P
    Pulley dia. 73.00
    Pulley dist. 42.50
    Radius 83.50
    D+ Size 6.30
    Radius 2 82.50
    Radius 3 82.50
    Radius 4 82.50
    Regulator type IR
    Rotation CW
    Servicing Austin-Healey
    Grooves/pulley 1
    Terminal W
    Voltage 14
    W plug type M5
    Total length 166.00 mm
    Width/holder arm 10.50
    Amp 70
  • Fordonsmatchning

    • OEM
      F032110497, nab900, 1457ir, 66021070, 66021155, 66921126, 9120690170

    • Konkurrentreferens
      A4036, ALT-4036, ALT16000, ALT4036, BAO3211, CAL11108, F042306030, F042A06030, 8el737662-001, 015.002.065, 28-8626, 5764, 12750N, 209248, 209248A, 301457RI, 301550RI, 66021126, 66021126K

    • Normaliserat artikelnummer
      a4036, alt16000, alt4036, bao3211, cal11108, f032110497, f042306030, f042a06030, nab900, 8el737662001, 1457ir, 5764, 12750n, 209248, 209248a, 288626, 301457ri, 301550ri, 015002065, 66021070, 66021126, 66021126k, 66021155, 66921126, 9120690170

    • Passar modeller
      Austin-Healey Model: Sprite Model series: Sprite MK Size of motor: 1.1 Brand of engine: 10CG-D-A Type description: Mk lll Body: Convertible From date: 01-03-1964 To date: 01-09-1966 Fuel: Gasoline Approved: Yes
      Austin-Healey Model: Sprite Model series: Sprite MK Size of motor: 1.3 Brand of engine: 10CG-D-A Type description: Mk lllA Body: Convertible From date: 01-03-1966 To date: 01-10-1971 Fuel: Gasoline Approved: Yes
      Various Agriculture Vehicles Model: Various Agriculture Vehicles Approved: Yes
