HC-Cargo Generator
HC-Cargo Generator
Artikelnr: F032116684

HC-Cargo Generator

Teknisk info:

Voltage: 28, Amp: 150, Rotation: CW, Radius: 93.00

Beskrivning

Generator 24V-150A , MB Buss 24V - 150A, ( - LIN - - - ) För Yourex produkt order 90-365-6550

Voltage: 28
Amp: 150
Width/holder arm: 80.00
Bracket hole: 10.00
Belt. adj. brackethole pos.: 10
Belt. adj. brackethole pos. 2: 50
Belt. adj. bracket hole 1: 12.50
Belt. adj. bracket hole 2: 12.50
Radius: 93.00
Radius 2: 90.00
Radius 3: 90.00
B+: M8
Rotation: CW
Plug no.: PL190
Total length mm: 199.00
Terminal type: COM
Pulley: w/o
Fan: IF
Regulator type: IR
Remarks: This Alternator has a COM terminal on the regulator. It is recommended that the OEM number is used to check suitability before ordering.

Filer

Specifikation

B+ M8
Belt. adj. bracket hole 1 12.50
Belt. adj. bracket hole 2 12.50
Belt. adj. brackethole pos. 10
Belt. adj. brackethole pos. 2 50
Plug no. PL190
Bracket hole 10.00
Pulley w/o
Radius 93.00
Radius 2 90.00
Radius 3 90.00
Regulator type IR
Remarks This Alternator has a COM terminal on the regulator. It is recommended that the OEM number is used to check suitability before ordering.
Rotation CW
Fan IF
Terminal type COM
Voltage 28
Total length 199.00 mm
Width/holder arm 80.00
Amp 150

  • OEM
    000 150 6550, A000 1506550, A0001506550, F032116684, 0124 655 125, 0124 655 161, 0986 085 300, 1986A00989, 116684, 0001506550, 0124655125, 0124655161

  • Konkurrentreferens
    A0669(BOSCH), A0669S, CAL10673, dra1445, LRA04299, 8EL012584-921, 48-7908, 555.514.150, 556.514.150, 20550N, 209503, 209503A, 443508, 444442, 554445RI, 12091003, 0986085300

  • Bilmärken
    Mercedes Benz Trucks & Buses

  • Normaliserat artikelnummer
    a0001506550, a0669bosch, a0669s, cal10673, dra1445, f032116684, lra04299, 8el012584921, 1986a00989, 20550n, 116684, 209503, 209503a, 443508, 444442, 487908, 554445ri, 0001506550, 12091003, 0124655125, 0124655161, 555514150, 556514150, 0986085300

  • Passar modeller
    Mercedes Benz Trucks & Buses Series: Citaro (O 530) Model: Ü Engine volume: 7.7 Year: 05.12-
    Mercedes Benz Trucks & Buses Series: Citaro 2 Model: G Engine volume: 7.7
    Mercedes Benz Trucks & Buses Series: Citaro 2 Model: GU Engine volume: 7.7
    Mercedes Benz Trucks & Buses Series: Citaro 2 Model: K Engine volume: 7.7
    Mercedes Benz Trucks & Buses Series: Citaro 2 Model: LE Engine volume: 7.7
    Mercedes Benz Trucks & Buses Series: Citaro 2 Model: U Engine volume: 7.7
    Mercedes Benz Trucks & Buses Series: Conecto Engine volume: 7.7 Year: 09.16-
    Mercedes-Benz Model: Actros Model series: 2045 LS Size of motor: 12.8 Brand of engine: OM460.984 Type description: Actros MP4 Body: Truck Tractor From date: 01-01-2019 Fuel: Diesel Approved: Yes
    Mercedes-Benz Model: Citaro Model series: Citaro (O 530) Size of motor: 10.7 Type description: Citaro Body: Bus From date: 01-05-2012 Fuel: Diesel Approved: Yes
    Mercedes-Benz Model: Citaro Model series: Citaro (O 530) Size of motor: 7.7 Type description: Citaro Body: Bus From date: 01-05-2012 Fuel: Diesel Approved: Yes
